| Camera | - Image Sensor: 2 × 1/2.5" Progressive Scan CMOS
- Max. Resolution: 3040 × 1368
- Min. Illumination: Color 0.003 Lux @ (F1.6, AGC ON), B/W 0 Lux with IR
- Shutter Time: 1/3 s to 1/100,000 s
- Day & Night: IR cut filter
- Angle Adjustment: Pan 0°-30°, Tilt -75°-75°
|
| Lens | - Lens Type: Fixed focal lens, dual lens, 2.8 mm
- Focal Length & FOV: 2.8 mm, Horizontal 180°, Vertical 81°
- Lens Mount: M12
- Iris Type: Fixed
- Aperture: F1.6
|
| DORI | - 2.8 mm: D 37 m, O 15 m, R 7 m, I 3.5 m
|
| Illuminator | - Supplement Light Type: IR
- Supplement Light Range: Up to 30 m
- Smart Supplement Light: Yes
- IR Wavelength: 850 nm
|
| Video | - Main Stream:
- 50 Hz: 25 fps (3040 × 1368)
- 60 Hz: 24 fps (3040 × 1368)
- Sub-Stream:
- 50 Hz: 25 fps (1200 × 536, 960 × 432)
- 60 Hz: 24 fps (1200 × 536, 960 × 432)
- Video Compression:
- Main stream: H.265+ / H.265 / H.264+ / H.264
- Sub-stream: H.265 / H.264 / MJPEG
- Video Bit Rate: 32 Kbps to 8 Mbps
- H.264 Type: Baseline Profile, Main Profile, High Profile
- H.265 Type: Main Profile
- Bit Rate Control: CBR, VBR
- Scalable Video Coding (SVC): H.264 and H.265 encoding
- Region of Interest (ROI): 1 fixed region for main stream
|
| Audio | - Audio Type: Mono sound
- Audio Compression: G.711 / G.722.1 / G.726 / MP2L2 / PCM / MP3 / AAC-LC
- Audio Bit Rate:
- 64 Kbps (G.711 ulaw / G.711 alaw)
- 16 Kbps (G.722.1)
- 16 Kbps (G.726)
- 32-192 Kbps (MP2L2)
- 8-320 Kbps (MP3)
- 16-64 Kbps (AAC-LC)
- Audio Sampling Rate: 8 / 16 / 32 / 44.1 / 48 kHz
- Environment Noise Filtering: Yes
|
| Network | - Protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, WebSocket, WebSockets
- Simultaneous Live View: Up to 6 channels
- API: ONVIF (Profile S, G, T), ISAPI, SDK
- User / Host: Up to 32 users (administrator, operator, user)
- Security: Password protection, HTTPS, 802.1X (EAP-MD5), watermark, IP filter, TLS 1.2, MAC authentication, audit log
- Network Storage: NAS (NFS, SMB/CIFS), ANR, memory card encryption & health detection
- Client: NVMS V3, X-VMS, LTS Connect
|
| Image | - Image Parameter Switch: Yes
- Image Settings: Saturation, brightness, contrast, sharpness, gain, white balance
- Day/Night Switch: Day, Night, Auto, Schedule
- Wide Dynamic Range (WDR): 120 dB
- SNR: ≥ 52 dB
- Image Enhancement: BLC, HLC, 3D DNR
- Privacy Mask: 4 programmable polygon masks
|
| Interface | - Ethernet Interface: 1 RJ45 10/100 M self-adaptive port
- On-Board Storage: microSD / microSDHC / microSDXC up to 512 GB
- Built-in Microphone: Yes
- Built-in Speaker: Max. 1.2 W, 95 dB @ 10 cm
- Audio I/O: 1 line in, 1 line out (terminal block)
- Alarm: 1 input, 1 output (max. 24 VDC, 1 A)
- Reset Key: Yes
|
| Events | - Motion detection (human & vehicle classification)
- Alarm I/O, flashing alarm light, audible alarm
- Scene change detection
- Line crossing, intrusion, region entrance, region exiting
|
| General | - Power: 12 VDC ±25%, max. 10.5 W; PoE 802.3af, max. 12.5 W
- Material: Metal base and cover
- Dimensions: Ø140 mm × 145.6 mm (Ø5.5" × 5.7")
- Package Dimensions: 230 × 230 × 230 mm (9" × 9" × 9")
- Weight: Approx. 940 g (2.1 lb.)
- With Package Weight: Approx. 1700 g (3.7 lb.)
- Operating Conditions: -30°C to 60°C, ≤95% humidity
- Languages: 33 languages supported
- General Functions: Anti-banding, heartbeat, flash log, pixel counter
- Flashing Light: Yes
|
| Approval | - EMC: FCC, CE-EMC, RCM, IC
- Safety: CB (IEC 62368-1), CE-LVD
- Environment: CE-RoHS, WEEE, REACH
- Protection: IP67
|
