| Camera | - Image Sensor: 1/2.8" Progressive Scan CMOS
- Min. Illumination: Color 0.005 Lux @ (F1.6, AGC on), B/W 0 Lux with IR
- Shutter Speed: 1/3 to 1/100,000 sec.
- Slow Shutter: Yes
- P/N: P/N
- Wide Dynamic Range: 120 dB
- Day & Night: IR cut filter
- Angle Adjustment: Pan 0°-360°, Tilt 0°-75°, Rotate 0°-360°
|
| Lens | - Lens Type: Fixed focal length, 2.8 mm and 4 mm optional
- Focal Length & FOV:
- 2.8 mm: Horizontal 107°, Vertical 57°, Diagonal 128°
- 4 mm: Horizontal 87°, Vertical 46°, Diagonal 105°
- Lens Mount: M12
- Iris Type: Fixed
- Aperture: F1.6
|
| DORI | - 2.8 mm: D 88 m, O 35 m, R 17 m, I 9 m
- 4 mm: D 108 m, O 43 m, R 22 m, I 11 m
|
| Illuminator | - Supplemental Light Type: IR
- Smart Supplemental Lighting: Yes
- IR Wavelength: 850 nm
- IR Range: Up to 98 ft (30 m)
|
| Video | - Max. Resolution: 3840 × 2160
- Main Stream:
- 50 Hz: 20 fps (3840 × 2160), 25 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
- 60 Hz: 20 fps (3840 × 2160), 30 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
- Sub Stream:
- 50 Hz: 25 fps (640 × 480, 640 × 360)
- 60 Hz: 30 fps (640 × 480, 640 × 360)
- Third Stream:
- 50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
- 60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
- Video Compression:
- Main stream: H.264 / H.264+ / H.265 / H.265+
- Sub-stream: MJPEG / H.264 / H.265
- Third stream: H.264 / H.265
- Video Bit Rate: 32 Kbps to 16 Mbps
- H.264 Type: Baseline / Main / High Profile
- H.265 Type: Main Profile
- Bit Rate Control: CBR / VBR
- Scalable Video Coding (SVC): H.264 and H.265 encoding
- Region of Interest (ROI): 1 fixed region for main stream and sub-stream
|
| Audio | - Audio Compression: G.711 ulaw / G.711 alaw / G.722.1 / G.726 / MP2L2 / PCM / MP3 / AAC
- Audio Bit Rates:
- 64 Kbps (G.711 ulaw / G.711 alaw)
- 16 Kbps (G.722.1)
- 16 Kbps (G.726)
- 16-64 Kbps (AAC)
- 32-192 Kbps (MP2L2)
- 8-320 Kbps (MP3)
- Audio Sampling Rates: 8 / 16 / 32 / 44.1 / 48 kHz
- Environment Noise Filtering: Yes
|
| Network | - Protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP
- Simultaneous Live View: Up to 6 channels
- API: Open Network Video Interface (Profile S, Profile G), ISAPI, SDK
- User / Host: Up to 32 users (administrator, operator, user)
- Security: Password protection, HTTPS encryption, IP filter, audit log, TLS 1.1/1.2, WSSE
- Network Storage: NAS (NFS, SMB / CIFS), ANR
|
| Imaging | - Image Parameter Switching: Yes
- Image Settings: Rotate, mirror, privacy mask, saturation, brightness, contrast, sharpness, gain, white balance
- Day / Night Switch: Day, Night, Auto, Schedule
- Image Enhancement: BLC, HLC, 3D DNR
- SNR: ≥ 52 dB
|
| Interface | - Ethernet Interface: 1 RJ45 10/100 Mbps
- On-board Storage: MicroSD / SDHC / SDXC up to 256 GB
- Built-in Microphone: Yes
- Hardware Reset: Yes
|
| Events | - Motion detection (human and vehicle classification)
- Video tampering alarm
- Face detection
- Line crossing detection
- Intrusion detection
|
| General | - Camera Material: Aluminum alloy body
- Camera Dimensions: Ø 5.0 × 3.8 in. (127.3 × 95.9 mm)
- Package Dimensions: 5.9 × 5.9 × 5.6 in. (150 × 150 × 141 mm)
- Camera Weight: Approx. 1.3 lbs (600 g)
- Package Weight: Approx. 2.0 lbs (891 g)
- Operating Temperature: -30°C to 60°C
- Humidity: ≤ 95% non-condensing
- General Functions: Anti-flicker, heartbeat, password reset via email, pixel counter
|
| Power | - Power Supply: 12 VDC ±25%, reverse polarity protection
- PoE: 802.3af, Class 3
- Power Consumption: Max. 6 W (DC), Max. 7.5 W (PoE)
- Power Interface: Ø 5.5 mm coaxial power plug
|
| Certifications | - EMC: FCC, CE-EMC, RCM, IC, KC
- Safety: UL, CB, CE-LVD
- Environmental: CE-RoHS, WEEE, Reach
- Protection: IP67
|
