| Camera | - Image Sensor: 1/3" Progressive Scan CMOS
- Max. Resolution: 2688 × 1520
- Shutter Speed: 1/3 sec. to 1/100,000 sec.
- Min. Illumination: Color: 0.005 Lux @ (F1.6, AGC on), B/W: 0 Lux with IR
- Day & Night: IR cut filter
- Angle Adjustment: Pan -30° to 30°, Tilt 0° to 75°, Rotate 0° to 360°
|
| Lens | - Lens Type: Fixed focal lens, 2.8 and 4 mm optional
- Focal Length & FOV:
- 2.8 mm: horizontal FOV°, vertical 55.9°, diagonal 123.8°
- 4 mm: horizontal 83.7°, vertical 43.0°, diagonal 100.3°
- Lens Mount: M12
- Iris Type: Fixed
- Aperture: F1.6
- Depth of Field:
- 2.8 mm: 1.4 m to ∞
- 4 mm: 1.6 m to ∞
|
| DORI | - 2.8 mm: D: 210 ft (64 m), O: 82 ft (25 m), R: 42 ft (13 m), I: 20 ft (6 m)
- 4 mm: D: 278 ft (85 m), O: 111 ft (34 m), R: 55 ft (17 m), I: 29 ft (9 m)
|
| Illuminator | - Supplemental Light Type: IR
- Supplemental Light Range: Up to 98 ft (30 m)
- Smart Supplemental Lighting: Yes
- IR Wavelength: 850 nm
|
| Video | - Main Stream:
- 50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
- 60 Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
- Sub Stream:
- 50 Hz: 25 fps (640 × 480, 640 × 360)
- 60 Hz: 30 fps (640 × 480, 640 × 360)
- Third Stream:
- 50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
- 60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
- *Supported under certain settings
- Video Compression:
- Main stream: H.265+ / H.265 / H.264+ / H.264
- Sub-stream: H.265 / H.264 / MJPEG
- Third stream: H.265 / H.264
- Video Bit Rates: 32 Kbps to 8 Mbps
- H.264 Type: Baseline / Main / High Profile
- H.265 Type: Main Profile
- Bit Rate Control: CBR / VBR
- Scalable Video Coding (SVC): H.264 and H.265 encoding
- Region of Interest (ROI): 1 fixed region for main stream and sub-stream
|
| Audio | - Environmental Noise Filtering: Yes
- Audio Sampling Rates: 8 / 16 / 32 / 44.1 / 48 kHz
- Audio Compressions: G.711 ulaw / G.711 alaw / G.722.1 / G.726 / MP2L2 / PCM / MP3 / AAC
- Audio Bit Rates:
- 64 Kbps (G.711 ulaw / G.711 alaw)
- 16 Kbps (G.722.1)
- 16 Kbps (G.726)
- 32-192 Kbps (MP2L2)
- 8-320 Kbps (MP3)
- 16-64 Kbps (AAC)
|
| Network | - Simultaneous Live View: Up to 6 channels
- API: Open Network Video Interface (Profile S, Profile G), ISAPI, SDK
- Protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X (except -W model), QoS, IPv6, UDP, Bonjour, SSL/TLS, PPPoE
- User / Host: Up to 32 users, 3 levels: administrator, operator, user
|
| Security | - Password protection, complicated password, HTTPS encryption, IP address filter, Security Audit Log, basic & digest authentication, TLS 1.1/1.2, WSSE
- Network Storage: NAS (NFS, SMB/CIFS), auto network replenishment (ANR)
- Web Browser:
- Plug-in required live view: IE 10, IE 11
- Plug-in free live view: Chrome 57.0+, Firefox 52.0+
- Local service: Chrome 57.0+, Firefox 52.0+
|
| Imaging | - Wide Dynamic Range (WDR): 120 dB
- SNR: ≥ 52 dB
- Day / Night Switch: Day, Night, Auto, Schedule
- Image Enhancement: BLC, HLC, 3D DNR
- Image Parameters Switch: Yes
- Image Settings: Rotate, mirror, privacy mask, saturation, brightness, contrast, sharpness, gain, white balance adjustable via client or browser
|
| Interface | - Ethernet Interface: 1 RJ45 10/100 Mbps self-adaptive port
- On-Board Storage: Built-in memory card slot, supports MicroSD cards up to 256 GB
- Built-in Microphone: Yes
- Audio: 1 input (line in), 1 output (line out), max 3.3 Vpp, non-equilibrium
- Alarm: 1 input, 1 output (max 12 VDC, 20 mA)
- Reset Key: Yes
|
| Event Types | - Basic Events: Motion detection (human/vehicle), video tampering, anomalies
- Smart Events: Line crossing, intrusion, face detection
- Linkage: Upload to FTP / NAS / memory card, notify surveillance center, trigger recording/capture, send email
- Deep Learning Functions: Perimeter protection, supports alarms by target type (human/vehicle)
|
| General | - Power: 12 VDC ±25%, 0.45 A, max 5.5 W, Ø5.5 mm plug, reverse polarity protection; PoE: 802.3 af, Class 3, 36-57 V, 0.18-0.11 A, max 6.5 W
- Camera Materials: Base aluminum, cover plastic
- Camera Dimensions: Ø4.3 × 2.3 in (Ø110 × 57.4 mm)
- Package Dimensions: 5.3 × 5.3 × 4.3 in (134 × 134 × 108 mm)
- Camera Weight: Approx. 0.8 lbs (380 g)
- Package Weight: Approx. 1.4 lbs (615 g)
- Storage Conditions: -22° to 140° F (-30° to 60° C), Humidity ≤ 95%
- Startup/Operating Conditions: Same as above
- Languages (33): English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
- General Functions: Anti-flicker, heartbeat, password reset via email, pixel counter
|
| Certifications | - EMC: FCC, CE-EMC, RCM, IC, KC
- Safety: UL, CB, CE-LVD
- Environmental: CE-RoHS, WEEE, REACH
- Electrical Safety Protections: IP67, IK8
|
