| Image Sensor | 1/2.7" Progressive Scan CMOS |
| Max. Resolution | 3840 × 2160 |
| Shutter Time | 1/3 s to 1/100,000 s |
| Min. Illumination | Color: 0.01 Lux @ (F2.0, AGC ON), B/W: 0 Lux with IR |
| Day & Night | IR cut filter |
| Angle Adjustment | - Pan: 0° to 360°
- Tilt: 0° to 75°
- Rotate: 0° to 360°
|
| Lens Type & FOV | - Fixed focal lens
- 2.8 mm
- Horizontal FOV: 113°
- Vertical FOV: 62°
- Diagonal FOV: 134°
|
| Lens Mount | M12 |
| Iris Type | Fixed |
| Aperture | F2.0 |
| DORI | - D: 79 m
- O: 31 m
- R: 15 m
- I: 7 m
|
| Illuminator | - Supplement Light Type: IR, White Light
- Supplement Light Range: Up to 30 m
- Smart Supplement Light: Yes
- IR Wavelength: 850 nm
|
| Main Stream | 60 Hz: 15 fps (3840 × 2160, 3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720) |
| Sub-Stream | 60 Hz: 15 fps (1280 × 720, 640 × 480, 640 × 360) |
| Video Compression | - Main stream: H.265+/H.265/H.264+/H.264
- Sub-stream: H.265/H.264/MJPEG
|
| Video Bit Rate | 32 Kbps to 16 Mbps |
| H.264 Type | Baseline Profile, Main Profile, High Profile |
| H.265 Type | Main Profile |
| Bit Rate Control | CBR, VBR |
| Region of Interest (ROI) | 1 fixed region for main stream |
| Scalable Video Coding (SVC) | H.264 and H.265 encoding |
| Audio | - Audio Type: Mono sound
- Environment Noise Filtering: Yes
- Audio Sampling Rate: 8 kHz/16 kHz
- Audio Compression: G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/AAC-LC
- Audio Bit Rate:
- 64 Kbps (G.711ulaw/G.711alaw)
- 16 Kbps (G.722.1)
- 16 Kbps (G.726)
- 32 to 160 Kbps (MP2L2)
- 16 to 64 Kbps (AAC-LC)
|
| Security | - Password protection, complicated password, watermark
- Basic and digest authentication for HTTP, WSSE and digest for Open Network Video Interface
- Security audit log, host authentication (MAC address)
|
| Simultaneous Live View | Up to 6 channels |
| API | Open Network Video Interface (Profile S, Profile T, Profile G), ISAPI, SDK |
| Protocols | TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IGMP, IPv6, UDP, QoS, FTP, SMTP, UPnP |
| User / Host | Up to 32 users; 3 user levels: administrator, operator, and user |
| Client | LTS connect, NVMS V3 |
| Web Browser | - Plug-in required live view: IE 10, IE 11
- Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+
|
| Wide Dynamic Range (WDR) | 120 dB |
| SNR | ≥ 52 dB |
| Day/Night Switch | Day, Night, Auto, Schedule |
| Image Enhancement | BLC, HLC, 3D DNR |
| Image Settings | Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser |
| Privacy Mask | 4 programmable polygon privacy masks |
| Ethernet Interface | 1 RJ45 10 M/100 M self-adaptive Ethernet port |
| On-Board Storage | Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB |
| Built-in Microphone | Yes |
| Reset Key | Yes |
| Basic Event | Motion detection (support alarm triggering by specified target types), video tampering alarm, exception |
| Linkage | - Upload to FTP/memory card (-F)
- Send email
- Notify surveillance center
- Trigger recording (-F)
- Trigger capture
|
| Power | - 12 VDC ± 25%, 0.41 A, max. 5 W, Ø5.5 mm coaxial power plug, reverse polarity protection
- PoE: IEEE 802.3af, Class 3, max. 6.5 W
|
| Material | Metal |
| Dimensions | Ø4.33" × 3.66" |
| Package Dimensions | 5.9" × 5.9" × 5.6" |
| Weight | Approx. 385 g (0.85 lb.) |
| With Package Weight | Approx. 586 g (1.3 lb.) |
| Storage Conditions | -22 °F to 140 °F; Humidity 95% or less (non-condensing) |
| Startup and Operating Conditions | -22 °F to 140 °F; Humidity 95% or less (non-condensing) |
| General Function | Heartbeat, anti-banding, mirror, password protection, password reset via email |
| Certifications | - EMC: CE-EMC, RCM, IC
- Safety: CB, CE-LVD, BIS
- Environment: CE-RoHS, WEEE, Reach
- Protection: IP67 (IEC 60529-2013)
|
