| Image Sensor | 1/2.5" Progressive Scan CMOS |
| Min. Illumination | 0.01 Lux @ (F2.0, AGC on) |
| Shutter Speed | 1/3 to 1/100,000 sec. |
| Slow Shutter | Yes |
| Wide Dynamic Range | 120 dB |
| Day & Night | ICR Cut |
| Angle Adjustment | - Pan: 0° to 360°
- Tilt: 0° to 75°
- Rotate: 0° to 360°
|
| Lens Type & FOV | - 2.8 mm
- Horizontal: 102°
- Vertical: 53°
- Diagonal: 123°
|
| Aperture | F2.0 |
| Lens Mount | M12 |
| IR Range | Up to 98 ft (30 m) |
| IR Wavelength | 850 nm |
| Smart Supplement Light | Yes |
| Max. Resolution | 3840 × 2160 |
| Main Stream | - 50 Hz: 12.5 fps (3840 × 2160, 2560 × 1440, 1920 × 1080, 1280 × 720)
- 60 Hz: 15 fps (3840 × 2160, 2592 × 1944, 1920 × 1080, 1280 × 720)
|
| Sub Stream | - 50 Hz: 25 fps (640 × 480, 640 × 360)
- 60 Hz: 30 fps (640 × 480, 640 × 360)
|
| Video Compression | - Main stream: H.265+ / H.265
- Sub-stream: H.265 / MJPEG
|
| Video Bit Rates | 32 Kbps to 16 Mbps |
| H.265 Type | Main Profile |
| H.265+ Support | Main stream supported |
| Bit Rate Control | CBR / VBR |
| Scalable Video Coding (SVC) | H.265 supports |
| Region of Interest (ROI) | 1 fixed region for main stream and sub-stream |
| Audio | - Environmental Noise Filtering: Yes
- Audio Sampling Rates: 8 / 16 / 32 / 44.1 / 48 kHz
- Audio Compression: G.711 ulaw / G.711 alaw / G.722.1 / G.726 / MP2L2 / PCM / MP3 / AAC
- Audio Bit Rates:
- 64 Kbps (G.711 ulaw)
- 64 Kbps (G.711 alaw)
- 16 Kbps (G.722.1)
- 16 Kbps (G.726)
- 32 - 192 Kbps (MP2L2)
- 16 - 64 Kbps (AAC)
- 8 - 320 Kbps (MP3)
|
| Simultaneous Live View | Up to 6 channels |
| API | Open Network Video Interface (PROFILE S, PROFILE G), ISAPI, SDK, ISUP |
| Protocols | TCP/IP, ICMP, DHCP, DNS, DDNS, HTTP, HTTPS, RTP, RTSP, NTP, UPnP, IGMP, IPv6, UDP, QoS, Bonjour, FTP, SMTP, 802.1x, SSL/TLS, PPPoE |
| User / Host | Up to 32 users; 3 levels: Administrator, Operator and User |
| Network Storage | Supports MicroSD / SDHC / SDXC cards (256 GB) for local storage, and NAS (NFS, SMB / CIFS), auto network replenishment (ANR) |
| Web Browser | - Plug-in required live view: IE 10, IE 11
- Local service: Chrome 57.0+, Firefox 52.0+
|
| Day / Night Switch | Day, Night, Auto, Schedule |
| Image Enhancement | BLC, HLC, 3D DNR |
| Image Settings | Mirror, saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or web browser |
| Privacy Mask | 4 regions of privacy masks |
| Built-in Microphone | Yes |
| On-board Storage | Built-in MicroSD / SDHC / SDXC slot, up to 256 GB |
| Hardware Reset | Yes |
| Communication Interface | 1 RJ45 10/100 Mbps self-adaptive Ethernet port |
| Basic Events | Motion detection, video tampering, exceptions / anomalies |
| Linkage Method | - Upload to FTP / NAS / memory card
- Notify surveillance center
- Send email
- Trigger recording
- Trigger capture
|
| Web Client Languages | 33 languages including English, Russian, German, French, Spanish, Ukrainian, etc. |
| General Functions | Anti-flicker, password protection, password reset via email |
| Software Reset | Yes |
| Storage Conditions | -22° to 140° F (-30° to 60° C); Humidity 95% or less (non-condensing) |
| Startup and Operating Conditions | -22° to 140° F (-30° to 60° C); Humidity 95% or less (non-condensing) |
| Power Supply | - 12 VDC ± 25%
- PoE: 802.3 af, Type 1 Class 3
|
| Power Consumption and Current | - 12 VDC, 0.4 A, max. 5 W
- PoE (802.3 af, 36 V to 57 V), 0.20 A to 0.1 A, max. 6.5 W
|
| Power Interface | Ø 5.5 mm coaxial power plug |
| Camera Materials | Aluminum alloy body |
| Camera Dimensions | Ø 4.33 × 3.20 in. (Ø 110 × 81.25 mm) |
| Package Dimensions | 5.9 × 5.9 × 5.6 in. (150 × 150 × 141 mm) |
| Camera Weight | Approx. 0.9 lbs (390 g) |
| Package Weight | Approx. 1.4 lbs (656 g) |
| Certifications | - EMC: FCC SDoC, CE-EMC, RCM, IC VoC, KC
- Safety: UL, CB, CE-LVD, BIS, LOA
- Environmental: CE-RoHS, WEEE, Reach
- Protections: IP67 (IEC 60529-2013)
|
