| Image Sensor | 1/3" Progressive Scan CMOS |
| Max. Resolution | 2560 × 1440 |
| Shutter Time | 1/3 s to 1/100,000 s |
| Min. Illumination | - Color: 0.005 Lux @ (F1.6, AGC ON)
- B/W: 0 Lux with IR
|
| Day & Night | IR cut filter |
| Angle Adjustment | - Pan: 0° to 360°
- Tilt: 0° to 75°
- Rotate: 0° to 360°
|
| Lens Type | Fixed focal lens |
| Focal Length & FOV | - 2.8 mm
- Horizontal FOV: 98°
- Vertical FOV: 54°
- Diagonal FOV: 114°
|
| Lens Mount | M12 |
| Iris Type | Fixed |
| Aperture | F1.6 |
| DORI | - D: 63 m
- O: 25 m
- R: 12 m
- I: 6 m
|
| Supplement Light Type | IR, White Light |
| Supplement Light Range | Up to 30 m |
| Smart Supplement Light | Yes |
| IR Wavelength | 850 nm |
| Main Stream | - 20 fps (2560 × 1440)
- 24 fps (1920 × 1080, 1280 × 720)
|
| Sub-Stream | 24 fps (1280 × 720, 640 × 480, 640 × 360) |
| Video Compression | - Main stream: H.265+/H.265/H.264+/H.264
- Sub-stream: H.265/H.264/MJPEG
|
| Video Bit Rate | 32 Kbps to 8 Mbps |
| H.264 Type | Baseline Profile, Main Profile, High Profile |
| H.265 Type | Main Profile |
| Bit Rate Control | CBR, VBR |
| Region of Interest (ROI) | 1 fixed region for main stream |
| Audio Type | Mono sound |
| Environment Noise Filtering | Yes |
| Audio Sampling Rate | 8 kHz/16 kHz |
| Audio Compression | G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/AAC-LC |
| Audio Bit Rate | - 64 Kbps (G.711 ulaw)
- 64 Kbps (G.711 alaw)
- 16 Kbps (G.722.1)
- 16 Kbps (G.726)
- 32-160 Kbps (MP2L2)
- 16-64 Kbps (AAC-LC)
|
| Security | - Password protection, complicated password, watermark
- Basic and digest authentication for HTTP
- WSSE and digest authentication for Open Network Video Interface
- Security audit log, host authentication (MAC address)
|
| Simultaneous Live View | Up to 6 channels |
| API | Open Network Video Interface (Profile S, Profile T, Profile G), ISAPI, SDK |
| Protocols | TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, RTCP, NTP, IGMP, IPv4, IPv6, UDP, QoS, FTP, SMTP |
| User/Host | Up to 32 users; 3 user levels: administrator, operator, and user |
| Client | NVMS, LTS Connect |
| Web Browser | - Plug-in required live view: IE 10, IE 11
- Local service: Chrome 57.0+, Firefox 52.0+
|
| Wide Dynamic Range (WDR) | 120 dB |
| SNR | ≥ 52 dB |
| Day/Night Switch | Day, Night, Auto, Schedule |
| Image Enhancement | BLC, HLC, 3D DNR |
| Image Settings | Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance, adjustable by client software or web browser |
| Privacy Mask | 4 programmable polygon privacy masks |
| Ethernet Interface | 1 RJ45 10 M/100 M self-adaptive Ethernet port |
| On-Board Storage | Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB |
| Built-in Microphone | Yes |
| Reset Key | Yes |
| Basic Event | Motion detection (support alarm triggering by human and vehicle), video tampering alarm, exception |
| Linkage | - Upload to FTP/memory card
- Send email
- Notify surveillance center
- Trigger recording
- Trigger capture
|
| Power | - 12 VDC ± 25%, 0.4 A, max. 5 W, Ø5.5 mm coaxial plug, reverse polarity protection
- PoE: IEEE 802.3af, Class 3, max. 6.5 W
|
| Material | Metal |
| Dimension | Ø4.3" × 3.5" |
| Package Dimension | 5.9" × 5.9" × 5.6" |
| Weight | Approx. 0.7 lb. |
| With Package Weight | Approx. 1.2 lb. |
| Storage Conditions | -22 °F to 140 °F. Humidity 95% or less (non-condensing) |
| Startup and Operating Conditions | -22 °F to 140 °F. Humidity 95% or less (non-condensing) |
| General Function | Heartbeat, anti-banding, mirror, password protection, password reset via email |
| EMC Approval | - FCC: 47 CFR Part 15, Subpart B
- CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4: 2011 +A1: 2014
- RCM: AS/NZS CISPR 32: 2015
- IC: ICES-003: Issue 7
|
| Safety Approval | - UL: UL 62368-1
- CB: IEC 62368-1: 2014+A11
- CE-LVD: EN 62368-1: 2014/A11: 2017
- BIS: IS 13252 (Part 1): 2010/IEC 60950-1: 2005
|
| Environment | - CE-RoHS: 2011/65/EU
- WEEE: 2012/19/EU
- Reach: Regulation (EC) No 1907/2006
|
| Protection | IP67 (IEC 60529-2013) |
