| Image Sensor | 1/3" Progressive Scan CMOS |
| Max. Resolution | 2560 × 1440 |
| Min. Illumination | - Color: 0.005 Lux @(F1.6, AGC ON)
- B/W: 0 Lux with IR
|
| Shutter Speed | 1/3 s to 1/100,000 s |
| Wide Dynamic Range | 120 dB |
| Day & Night | IR Cut Filter |
| Angle Adjustment | - Pan: 0° to 355°
- Tilt: 0° to 70°
- Rotation: 0° to 355°
|
| Lens Type | Varifocal Lens, motorized lens, 2.8 to 12 mm |
| Focal Length & FOV | - 2.8 to 12 mm
- Horizontal FOV: 102° to 31°
- Vertical FOV: 54° to 17°
- Diagonal FOV: 123° to 35°
|
| Lens Mount | Ø 14 |
| Iris Type | Fixed |
| Aperture | F1.6 |
| IR Wavelength | 850 nm |
| IR Range | Up to 98 ft (30 m) |
| Main Stream | - 50 Hz: 20 fps (2560 × 1440), 25 fps (2304 × 1296, 1920 × 1080, 1280 × 720)
- 60 Hz: 20 fps (2560 × 1440), 30 fps (2304 × 1296, 1920 × 1080, 1280 × 720)
|
| Sub-Stream | - 50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360)
- 60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360)
|
| Video Compression | - Main stream: H.265+/H.265/H.264+/H.264
- Sub-stream: H.265/H.264/MJPEG
|
| Video Bit Rate | 32 Kbps to 8 Mbps |
| H.264 Type | Baseline Profile/Main Profile/High Profile |
| H.265 Type | Main Profile |
| Region of Interest (ROI) | 1 fixed region for main stream |
| Network Protocols | - TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv6, Bonjour, IPv4, UDP, SSL/TLS
|
| Simultaneous Live View | Up to 6 channels |
| API | Open Network Video Interface, ISAPI |
| User/Host | Up to 32 users; 3 levels: administrator, operator, user |
| Web Browser | - Plug-in required live view: IE 10+
- Plug-in free live view: Chrome 57.0+, Firefox 52.0+
- Local service: Chrome 57.0+, Firefox 52.0+
|
| Image Settings | Saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or web browser |
| Day/Night Switch | Auto, Schedule, Day, Night |
| Image Enhancement | BLC, 3D DNR |
| Ethernet Interface | 1 RJ45 10 M/100 M self-adaptive Ethernet port |
| On-Board Storage | Built-in memory card slot, support microSD card, up to 256 GB |
| Reset Key | Yes |
| Basic Event | Motion detection, video tampering alarm, exception |
| Linkage | - Upload to FTP
- Notify surveillance center
- Send email
- Upload to memory card
- Trigger recording
- Trigger capture
|
| Power | - 12 VDC ± 25%, 0.75 A, max. 9 W, Ø 5.5 mm coaxial power plug
- PoE: 802.3af, Class 3, 36 V to 57 V, 0.27 A to 0.17 A, max. 10 W
|
| Camera Material | Metal and Plastic |
| Camera Dimension | Ø 129.4 mm × 116.4 mm (Ø 5.1" × 4.6") |
| Package Dimension | 170 mm × 170 mm × 150 mm (6.7" × 6.7" × 5.9") |
| Camera Weight | Approx. 560 g (1.2 lb.) |
| With Package Weight | Approx. 850 g (1.9 lb.) |
| Storage Conditions | -30 °C to 60 °C (22 °F to +140 °F). Humidity 95% or less (non-condensing) |
| Startup and Operating Conditions | -30 °C to 60 °C (22 °F to +140 °F). Humidity 95% or less (non-condensing) |
| Language | English |
| General Function | - Anti-flicker
- Heartbeat
- Mirror
- Password protection
- Privacy mask
- Watermark
- IP address filter
|
| EMC Approval | - FCC SDoC (47 CFR Part 15, Subpart B)
- CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014)
- RCM (AS/NZS CISPR 32: 2015)
- IC VoC (ICES-003: Issue 6, 2016)
- KC (KN 32: 2015, KN 35: 2015)
|
| Safety Approval | - UL (UL 60950-1)
- CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014)
- CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014)
- BIS (IS 13252(Part 1):2010+A1:2013+A2:2015)
|
| Environment | - CE-RoHS (2011/65/EU)
- WEEE (2012/19/EU)
- Reach (Regulation (EC) No 1907/2006)
|
| Electrical Safety Protection | IP67 (IEC 60529-2013) |
