| N883 Series - Lorex 4K Pro Network Video Recorder |
| Video Transmission Technology | IP |
| Channels | 16, 32 channel (32ch. includes 16ch. PoE Switch) |
| Video Input | 16ch: 16 x PoE |
| Video Outputs | 1 x VGA/1 x HDMI |
| Audio Input | 1 x RCA |
| Audio Output | 1 x RCA |
| Alarm IN | 4 channels |
| Alarm OUT | 2 channels |
| System Navigation | USB Mouse/Front Panel Buttons |
| Display Output Resolution | Up to 4K UHD, Auto Detect |
| Live Display | - 16ch: 1/4/8/9/16
- 32Ch: 1/4/8/9/16/25/32
|
| Live Display Speed (Max) | up to 4ch 4K@30fps |
| OSD | On/Off |
| Video Compression | H.265/H.264 |
| Recording Resolution | 4K (8MP)/5MP/4MP/3MP/ 1080p/720p |
| Recording Frame Rate | up to 30fps |
| Recording Schedule | - Schedule recordings through Continuoun
- Motion
- Smart Motion (Person and Vehicle)
- Face Detection
- Alarm
- Day
- Hour per channel
|
| Back-Up Media | USB, USB HDD |
| Simultaneous Playback | 4ch@4K/30fps |
| Playback Speed | Variable Max 16x |
| Search | - By Time/Date
- All Motion Events or Smart Motion (Person/Vehicle)
- Area Search
|
| Hard Drive Bays | 2 Bays |
| Hard Drive Capacity | Up to 2 x 10TB (SATA) |
| Backup Media | USB Flash Drive & USB HDD |
| Storage Mirroring | Yes |
| Smart Motion Detection | Support for Person and Vehicle Detection |
| Mobile Viewing | |
| Compatible APP | Lorex Cloud |
| PC/Mac Remote Viewing | Yes/Lorex Cloud |
| Email Notification | Text and Snapshot |
| Network Interface | |
| Network Bit Rate | 320 Mbps total |
| DDNS | Yes (Optional) |
| USB interface | USB 2.0 x 2 |
| Operating Temperature | 14° ~ 131°F / -10° ~ 55°C |
| FW Upgrade | USB/Network |
| Watchdog Function | Yes |
| Power Consumption | Approx. 15W (no HDD included) |
| Supply Voltage | 100VAC-240VAC, 50/60hz |
| Total PoE Power Output | 16 PoE: Max 25.5W for single port, 2200W total |
| Unit Dimensions (W x D x H) | 14.7 x 12.9 x 2.1" / 375 x 327 x 53 mm |
| Unit Weight | 5.8 lbs / 2.6 kg (excl. HDD) |
| Humidity | 10 ~ 90% RH |
| Package | Plain Box |
| Package Weight | 11.6lb / 5.7kg |
| Package Dimensions (W x D x H) | 21.5 x 16.3 x 6.7" / 546 x 414 x 170mm |
| LNE9282B / LNE9292B Series - 4K Fixed Smart IP Dome Security Camera |
| Video Compression | H.265/H.264H (Main Stream & Sub Stream) |
| Video Transmission Technology | IP |
| Image Sensor | 8MP/4K 1/2.8" CMOS |
| Video Format | NTSC |
| Viewing Angle (Horizontal) | 113° - 31° |
| Lens/Lens Type | 2.7mm to 13.5mm F1.5 / Motorized Varifocal |
| Resolution/Frame Rate | Up to 4K (8MP) @30fps |
| Effective Pixels | H:3840 x V:2160 |
| HDR | Yes |
| Termination | RJ45 |
| Microphone/Speaker | No/No |
| Siren | No |
| Two-way Talk | No |
| IR Night Vision Range (Ambient/Total Darkness) | 150ft (46m)/ 98ft (30m) |
| Smart Motion Detection | Yes - Person and Vehicle Detection |
| Deterrence | No |
| Color Night Vision | Yes |
| Body Material | Aluminum Alloy |
| SD Card Slot | Yes |
| Power Requirements | PoE (Power over Ethernet Class -802.3af) / 12V DC |
| Power Consumption (max) | 917mA / 11W |
| Camera Dimensions (W x D x H) | 3.6 x 9.5 x 3.6" / 91 x 242 x 91mm |
| Camera Weight | 1.8lbs / 0.82kg |
| Operating Temperature | -40°F ~ 140°F /-40°C ~ 60°C |
| Humidity | < 95% RH |
| Environmental Rating | IP67 (Indoor/Outdoor) |
| Junction Boxes | ACJNCD3BKB (Black) |
| Package Type | Plain box |
| Package Dimensions (W x D x H) | 17.4 x 6.5 x 6.2" / 442 x 165 x 158mm |
| Package Weight | 4.6lb / 2.06kg |
| ACCLPS263B - 16-Channel PoE+ Switch |
| Ports | - 16x 10/100Base-TX RJ-45 Auto-MDI/MDI-X ports
- 1x 10/100/1000Base-T RJ-45 Auto-MDI/MDI-X port
- 1x 1000Base-X SFP interface, shared with port 17
|
| PoE Standard | IEEE 802.3af / 802.3at |
| PoE Power Output | 30.8 watts with 51V DC output ability (maximum) |
| Total Power Output | 220 watts across ports 1~16 |
| PoE Class | Class 0/1/2/3/4 |
| Standard Compliance | - IEEE 802.3 Ethernet
- IEEE 802.3u Fast Ethernet
- IEEE 802.3ab Gigabit Ethernet
- IEEE 802.3x Full-duplex flow control
- IEEE 802.3af Power over Ethernet
- IEEE 802.3at Power over Ethernet Plus
|
| Operating Humidity | 5 ~ 95% (non-condensing) |
| Operating Temperature | 32° ~ 122°F / 0° ~ 50°C |
| Power Input | 100~240V AC, 50/60Hz, 3.5A |
| Dimensions (W x D x H) | 17.36 x 8.20 x 1.73" / 440mm x 208 x 44mm |
| Weight | 5.8lbs / 2.6kg |
| Package Weight | 8.1lbs / 3.7kg |
| Package Dimensions (W x D x H) | 21.8 x 11.6 x 3.4" / 553 x 294 x 86mm |
