Network Video Recorder NVR N843A82 |
Video Transmission Technology | IP |
Channels | 8 Channels |
Video Input | 8 x PoE |
Video Outputs | 1 x VGA/1 x HDMI |
Audio Input | 1 ch: RCA type |
Audio Output | 1 ch: RCA type |
Display Output Resolution | Up to 4K UHD, Auto Detect |
Live Display | 1,4,8 |
Live Display Speed (Max) | 240fps NTSC/200fps PAL |
OSD | On/Off |
System Navigation | USB Mouse |
Recording Resolution | 4K (8MP)/5MP/4MP/3MP/1080p/720p |
Recording Frame Rate | - 4K (8MP) at15fps
- 5MP at30fps
- 4MP at30fps
- 1080p at30fps
- 720p at30fps
|
Recording Schedule | Schedule recordings through Continuous, Motion, Smart Motion (Person and Vehicle), Face Detection, Alarm, Day, Hour per channel |
Back-up File Format | DAV/ASF/AVI/MP4 |
Video Compression | H.265/H.264 |
Simultaneous Playback | Up to 4 channels, synchronized |
Playback Speed | Variable Max 8x |
Search | By Time/Date, All Motion Events or Smart Motion (Person/Vehicle5 ), Area Search |
Hard Drive Bays | 1 Bay |
Hard Drive Capacity | Up to 8TB (SATA) |
Backup Media | USB Flash Drive & USB HDD |
Storage Mirroring | Yes |
Special Features | - Smart Motion Detection Support - Yes for Person and Vehicle detection
- Wired/Wireless Fusion support - Yes
- Lorex Sensor Compatible - Yes
- Face Detection Support - Yes
- Mask Detection Support - Yes
- Lorex Safeguard™ (Missing Object and Object Left Behind) - Yes
- Active Deterrence Support - Yes
- Active View Support - Yes
- Panic Button - Yes
- Smart Search - Yes
|
Voice Control | Amazon Alexa™, Google Assistant™ |
Streaming Options | Chromecast™, Apple TV™, Amazon Echo Show™, Google Home Hub™ |
Mobile Viewing | Android, iOS |
Compatible APP | Lorex Home™ |
PC/Mac Remote Viewing | Yes/Lorex Cloud™ client |
Email Notification | Text and Snapshot |
Network Interface | 10/100 Base-TX, RJ45 |
Network Bit Rate | 80Mbps total, 48~8192kbps per camera |
USB interface | USB 2.0 x 2 |
FW Upgrade | USB/Network |
Watchdog Function | Yes |
Power Consumption | Approx. 8.3W (HDD excl.) |
Supply Voltage | 100VAC-240VAC, 50/60hz, DC 53V/1.8A |
Total PoE Power Output | PoE: Max 25.5W for single port, 72W total |
Unit Dimensions (W x D x H) | 12.9 x 9.6 x 2.1" / 328 x 245 x 53 mm |
Unit Weight | 2.75 lbs. / 1.26 kg (excl. HDD) |
Operating Temperature | 14° ~ 131°F / -10° ~ 55°C |
Humidity | 10 ~ 90% RH |
Package | Plain Box |
Package Weight | 6.6lb / 2.99kg |
Package Dimensions (W x D x H) | 15.51 x 13.2 x 5.4" / 394 x 335 x 137mm |
Package Cube | 0.64cbf / 0.018cbm |
Bullet Camera E841CD-E |
Video Transmission Technology | IP |
Image Sensor | 8MP/4K 1/2.7" CMOS |
Video Format | NTSC |
Video Compression | H.265/H.264H (Main Stream & Sub Stream) |
Viewing Angle (Horizontal) | 105° |
Lens/Lens type | 2.8mm F2.0 / Fixed |
Resolution/Frame rate | 4K(8MP) at 15fps, 5MP at 30fps, 1080p at 30fps, 720p at 30fps |
Effective Pixels | H:3840 x V:2160 |
HDR | Yes |
Termination | RJ45 |
Microphone/Speaker | No/Yes (Listen-in Audio) |
Siren | No/No |
2-Way Talk | No |
Night Vision Range (Ambient/Total Darkness) | 130ft (40m)/ 90ft (27m) |
Color Night Vision | Yes |
Body Material | Aluminum Alloy |
Power Requirements | PoE (Power over Ethernet Class -802.3af)/12V DC |
Power Consumption (max) | 640mA / 7.68W |
Camera Dimensions (W x D x H) | 4.0" x 3.3" (101mm x 83mm) |
Camera Weight | 0.79lbs/0.36kg |
Operating Temperature | -22°F ~ 140°F / -30°C ~ 60°C |
Humidity | < 95% RH |
Environmental Rating | IP67 (Indoor/Outdoor) |
Junction Box | Compatible with ACJNCD3B |
Package Type | Retail Box |
Package Weight | 3.3lb / 1.4kg |
Package Dimensions (W x D x H) | 11.3 x 6.2 x 5.1" / 287 x 157 x 129mm |
Package Cube | 0.20 cbf / 0.005cbm |
