Buy Lovejoy 69790493345, DI-6 Type 110-6 Spacer Sub-Assemblies

info@MegaDepot.com

(800) 884-5767
+1 (332) 900-3727 (Intl.)

Options and Related Products

Dimension BSE:: Dimension BSE: 3-1/2"

Features

Designed to meet the API 610 Standard
Unitized disc pack
Infinite life if properly aligned
Torsionally rigid without any back lash
No need for lubrication or maintenance
No wearing parts and high resistance to harsh environmental conditions

The DI Type coupling has a "Drop-In" spacer assembly that is assembled at the factory. The coupling consists of two hubs and a spacer assembly comprising of the spacer, two unitized disc packs, and two guard rings. The disc packs are bolted to the spacer and guard rings at the factory using the torque values recommended by Lovejoy for the disc pack bolts. With the hubs mounted on the shafts, the entire disc pack assembly can be "Dropped In" place between the two hubs. The hubs are piloted to ensure proper centering of the spacer assembly. This piloting serves as an anti-flail feature and aids in the coupling's ability to meet the balance standards mandated by API. This style coupling is designed to meet the balance and anti-flail requirements specified in API-610.

See more product information See less

We aim to show you accurate product information. Here you will find what the manufacturers have provided us with. See our disclaimer.

Technical Details

Reviews

Hub Style	Standard
Type	Disc
Style	Spacer Assembly
Weight	6.38 lb
Color	Metallic
Coupling Series	DI-6
Coupling Type	Drop in Spacer Assembly
Weight (Complete Coupling w/ Max. Bores)	12.00 lb (6.00 kg)
Height	4.53 in
Between Shaft Ends	3.50 in
Width	4.53 in
Cubic inches	71.82315 in3
Coupling Size	110-6
Length thru Bore	1.97 in (50.04 mm)
Outside Diameter	2.870 in (73.00 mm)
Overall Length	7.440 in (188.976 mm)
Max. Bore (Dimensions ID)	2.06 in (52 mm)
Flange Diameter (Dimension FD)	4.53 in (115.00 mm)
Dimension PW	3.500 in (88.90 mm)
Dimension S	2.410 in (61.00 mm)
Distance between Shaft Ends (Dimension BSE)	3.5 in (108 mm)
Temperature	-40 to 450 °F
Nominal Torque	575.00 in-lb
Max. Torque	10200 in-lb (1150 N-m)
Max. Speed (Unbalanced)	7200 rpm
Max. Speed (Balanced)	18000 rpm
Axial Misalignment ( Ka)	0.083 in (2.1 mm)
Max. Angular Misalignment	1.50 °
Torsional Stiffness x 10⁶	3.4 in-lb/rad (0.40 Nm/rad)
Rated Power at 100 rpm	8 hp (6 kW)

Notes

* Free Ground Shipping within the continental U.S. only (excludes Alaska, Hawaii, PO Boxes and APO/FPO addresses).

Product Details

Hub Style	Standard
Type	Disc
Style	Spacer Assembly
Weight	6.38 lb
Color	Metallic
Coupling Series	DI-6
Coupling Type	Drop in Spacer Assembly
Weight (Complete Coupling w/ Max. Bores)	12.00 lb (6.00 kg)
Height	4.53 in
Between Shaft Ends	3.50 in
Width	4.53 in
Cubic inches	71.82315 in3
Coupling Size	110-6
Length thru Bore	1.97 in (50.04 mm)
Outside Diameter	2.870 in (73.00 mm)
Overall Length	7.440 in (188.976 mm)
Max. Bore (Dimensions ID)	2.06 in (52 mm)
Flange Diameter (Dimension FD)	4.53 in (115.00 mm)
Dimension PW	3.500 in (88.90 mm)
Dimension S	2.410 in (61.00 mm)
Distance between Shaft Ends (Dimension BSE)	3.5 in (108 mm)
Temperature	-40 to 450 °F
Nominal Torque	575.00 in-lb
Max. Torque	10200 in-lb (1150 N-m)
Max. Speed (Unbalanced)	7200 rpm
Max. Speed (Balanced)	18000 rpm
Axial Misalignment ( Ka)	0.083 in (2.1 mm)
Max. Angular Misalignment	1.50 °
Torsional Stiffness x 10⁶	3.4 in-lb/rad (0.40 Nm/rad)
Rated Power at 100 rpm	8 hp (6 kW)

Note

Note: Please read description carefully. Do not base your order on the picture presented.
