Buy Lovejoy 68514459724, L070 L Type Hub with Keyway - Metric Bore, 18 mm

info@MegaDepot.com

(800) 884-5767
+1 (332) 900-3727 (Intl.)

Options and Related Products

Lovejoy, 68514459724, L070 L Type Hub with Keyway - Metric Bore, 18 mm, 6 x 2.8 mm

Features:

We aim to show you accurate product information. Here you will find what the manufacturers have provided us with. See our disclaimer.

Technical Details

Hub Style	1
Coupling Type	Jaw
Material	Sintered Iron
Color	Metallic
Elastomeric Member	SOX (NBR) Rubber
Weight	0.20 lb
Weight (Complete Coupling w/ Min. Bore)	0.40 lb
Weight (Complete Coupling w/ Max. Bore)	0.60 lb
Bore Size	18.00 mm
Coupling Size	L070
Keyway Size (W x D)	6 x 2.8 mm
Length thru Bore	0.750 in (19.05 mm)
Overall Length	1.980 in (50.29 mm)
Outside Diameter	1.36 in (34.54 mm)
Min. Bore	0.250 in (6.00 mm)
Max. Bore	0.750 in (19.00 mm)
Hub Length	1.230 in (31.24 mm)
Nominal Torque	43.20 in x lb (4.88 N x m)
Max. Speed	14000.00 rpm
Rated HP at 100 rpm	0.07 hp
Rated HP at 1,200 rpm	0.84 hp
Rated HP at 1,800 rpm	1.23 hp
Rated HP at 3,600 rpm	2.52 hp

Notes

* Free Ground Shipping within the continental U.S. only (excludes Alaska, Hawaii, PO Boxes and APO/FPO addresses).

Hub Style	1
Coupling Type	Jaw
Material	Sintered Iron
Color	Metallic
Elastomeric Member	SOX (NBR) Rubber
Weight	0.20 lb
Weight (Complete Coupling w/ Min. Bore)	0.40 lb
Weight (Complete Coupling w/ Max. Bore)	0.60 lb
Bore Size	18.00 mm
Coupling Size	L070
Keyway Size (W x D)	6 x 2.8 mm
Length thru Bore	0.750 in (19.05 mm)
Overall Length	1.980 in (50.29 mm)
Outside Diameter	1.36 in (34.54 mm)
Min. Bore	0.250 in (6.00 mm)
Max. Bore	0.750 in (19.00 mm)
Hub Length	1.230 in (31.24 mm)
Nominal Torque	43.20 in x lb (4.88 N x m)
Max. Speed	14000.00 rpm
Rated HP at 100 rpm	0.07 hp
Rated HP at 1,200 rpm	0.84 hp
Rated HP at 1,800 rpm	1.23 hp
Rated HP at 3,600 rpm	2.52 hp

Note: Please read description carefully. Do not base your order on the picture presented.
