Lovejoy, 68514458246, L075 L Type Hub with Keyway - Metric Bore, 22 mm, 6 x 2.8 mm

Features:

We aim to show you accurate product information. Here you will find what the manufacturers have provided us with. See our disclaimer.

Technical Details

Hub Style	1
Coupling Type	Jaw
Material	Sintered Iron
Color	Metallic
Elastomeric Member	SOX (NBR) Rubber
Weight	0.38 lb
Weight (Complete Coupling w/ Min. Bore)	0.80 lb
Weight (Complete Coupling w/ Max. Bore)	1.00 lb
Bore Size	22.00 mm
Coupling Size	L075
Keyway Size (W x D)	6 x 2.8 mm
Length thru Bore	0.82 in (20.83 mm)
Overall Length	2.130 in (54.10 mm)
Outside Diameter	1.75 in (44.45 mm)
Min. Bore	0.250 in (6.00 mm)
Max. Bore	0.875 in (22.00 mm)
Hub Length	1.32 in (33.53 mm)
Nominal Torque	90.00 in x lb (10.17 N x m)
Max. Speed	11000.00 rpm
Rated HP at 100 rpm	0.14 hp
Rated HP at 1,200 rpm	1.68 hp
Rated HP at 1,800 rpm	2.57 hp
Rated HP at 3,600 rpm	5.04 hp

Notes

* Free Ground Shipping within the continental U.S. only (excludes Alaska, Hawaii, PO Boxes and APO/FPO addresses).

Hub Style	1
Coupling Type	Jaw
Material	Sintered Iron
Color	Metallic
Elastomeric Member	SOX (NBR) Rubber
Weight	0.38 lb
Weight (Complete Coupling w/ Min. Bore)	0.80 lb
Weight (Complete Coupling w/ Max. Bore)	1.00 lb
Bore Size	22.00 mm
Coupling Size	L075
Keyway Size (W x D)	6 x 2.8 mm
Length thru Bore	0.82 in (20.83 mm)
Overall Length	2.130 in (54.10 mm)
Outside Diameter	1.75 in (44.45 mm)
Min. Bore	0.250 in (6.00 mm)
Max. Bore	0.875 in (22.00 mm)
Hub Length	1.32 in (33.53 mm)
Nominal Torque	90.00 in x lb (10.17 N x m)
Max. Speed	11000.00 rpm
Rated HP at 100 rpm	0.14 hp
Rated HP at 1,200 rpm	1.68 hp
Rated HP at 1,800 rpm	2.57 hp
Rated HP at 3,600 rpm	5.04 hp

Note: Please read description carefully. Do not base your order on the picture presented.
