Buy Lovejoy 68514458036, L050 L Type Hub without Keyway - Metric Bore

info@MegaDepot.com

(800) 884-5767
+1 (332) 900-3727 (Intl.)

Options and Related Products

Lovejoy, 68514458036, L050 L Type Hub without Keyway - Metric Bore, 14 mm, No Keyway

Features:

We aim to show you accurate product information. Here you will find what the manufacturers have provided us with. See our disclaimer.

Technical Details

Hub Style	1
Coupling Type	Jaw
Material	Sintered Iron
Color	Metallic
Elastomeric Member	SOX (NBR) Rubber
Weight	0.11 lb
Weight (Complete Coupling w/ Min. Bore)	0.20 lb
Weight (Complete Coupling w/ Max. Bore)	0.30 lb
Bore Size	14.00 mm
Coupling Size	L050
Keyway Size (W x D)	No Keyway
Length thru Bore	0.620 in (15.75 mm)
Overall Length	1.710 in (43.43 mm)
Min. Bore	0.250 in (6.00 mm)
Max. Bore	0.625 in (16.00 mm)
Hub Length	1.100 in (27.94 mm)
Nominal Torque	26.30 in x lb (2.97 N x m)
Max. Speed	18000 rpm
Rated HP at 100 rpm	0.04 hp
Rated HP at 1,200 rpm	0.50 hp
Rated HP at 1,800 rpm	0.75 hp
Rated HP at 3,600 rpm	1.51 hp

Notes

* Free Ground Shipping within the continental U.S. only (excludes Alaska, Hawaii, PO Boxes and APO/FPO addresses).

Hub Style	1
Coupling Type	Jaw
Material	Sintered Iron
Color	Metallic
Elastomeric Member	SOX (NBR) Rubber
Weight	0.11 lb
Weight (Complete Coupling w/ Min. Bore)	0.20 lb
Weight (Complete Coupling w/ Max. Bore)	0.30 lb
Bore Size	14.00 mm
Coupling Size	L050
Keyway Size (W x D)	No Keyway
Length thru Bore	0.620 in (15.75 mm)
Overall Length	1.710 in (43.43 mm)
Min. Bore	0.250 in (6.00 mm)
Max. Bore	0.625 in (16.00 mm)
Hub Length	1.100 in (27.94 mm)
Nominal Torque	26.30 in x lb (2.97 N x m)
Max. Speed	18000 rpm
Rated HP at 100 rpm	0.04 hp
Rated HP at 1,200 rpm	0.50 hp
Rated HP at 1,800 rpm	0.75 hp
Rated HP at 3,600 rpm	1.51 hp

Note: Please read description carefully. Do not base your order on the picture presented.
