Buy Lovejoy 68514452828, L090 L Type Hub with Keyway - Metric Bore, 10 mm

info@MegaDepot.com

(800) 884-5767
+1 (332) 900-3727 (Intl.)

Options and Related Products

Lovejoy, 68514452828, L090 L Type Hub with Keyway - Metric Bore, 10 mm, 3 x 1.4 mm

Features:

Standard L Type coupling hub materials are either sintered iron (L035-L190) or cast iron (L225-L276).
The L Type coupling consists of two standard L Type hubs and one spider.
Fail-safe - will still perform if elastomer fails
No metal to metal contact
Resistant to oil, dirt, sand, moisture and grease

We aim to show you accurate product information. Here you will find what the manufacturers have provided us with. See our disclaimer.

Technical Details

Hub Style	1
Coupling Type	Jaw
Material	Sintered Iron
Color	Metallic
Elastomeric Member	SOX (NBR) Rubber
Weight	0.68 lb
Weight (Complete Coupling w/ Min. Bore)	1.20 lb
Weight (Complete Coupling w/ Max. Bore)	1.50 lb
Bore Size	10.00 mm
Coupling Size	L090
Keyway Size (W x D)	3 x 1.4 mm
Length thru Bore	0.82 in (20.83 mm)
Overall Length	2.150 in (54.61 mm)
Outside Diameter	2.11 in (53.59 mm)
Min. Bore	0.250 in (6.00 mm)
Max. Bore	1.000 in (25.00 mm)
Hub Length	1.34 in (34.04 mm)
Dimension G	0.52 in (13.21 mm)
Dimension SL	0.440 in (11.18 mm)
Cubic inches	5.96581 in3
Nominal Torque	144 in x lb (16.27 N x m)
Max. Speed	9000.00 rpm
Rated HP at 100 rpm	0.23 hp
Rated HP at 1,200 rpm	2.76 hp
Rated HP at 1,800 rpm	4.11 hp
Rated HP at 3,600 rpm	8.28 hp

Notes

* Free Ground Shipping within the continental U.S. only (excludes Alaska, Hawaii, PO Boxes and APO/FPO addresses).

Hub Style	1
Coupling Type	Jaw
Material	Sintered Iron
Color	Metallic
Elastomeric Member	SOX (NBR) Rubber
Weight	0.68 lb
Weight (Complete Coupling w/ Min. Bore)	1.20 lb
Weight (Complete Coupling w/ Max. Bore)	1.50 lb
Bore Size	10.00 mm
Coupling Size	L090
Keyway Size (W x D)	3 x 1.4 mm
Length thru Bore	0.82 in (20.83 mm)
Overall Length	2.150 in (54.61 mm)
Outside Diameter	2.11 in (53.59 mm)
Min. Bore	0.250 in (6.00 mm)
Max. Bore	1.000 in (25.00 mm)
Hub Length	1.34 in (34.04 mm)
Dimension G	0.52 in (13.21 mm)
Dimension SL	0.440 in (11.18 mm)
Cubic inches	5.96581 in3
Nominal Torque	144 in x lb (16.27 N x m)
Max. Speed	9000.00 rpm
Rated HP at 100 rpm	0.23 hp
Rated HP at 1,200 rpm	2.76 hp
Rated HP at 1,800 rpm	4.11 hp
Rated HP at 3,600 rpm	8.28 hp

Note: Please read description carefully. Do not base your order on the picture presented.
