Lovejoy 68514436758 1-3/4" SC Type Space Coupling Hub w/ Rough Stock

Lovejoy, 68514436758, 1-3/4" SC Type Space Coupling Hub with Rough Stock Bore

Features

• Specifically designed for the pump industry, this coupling accommodates industry standard as well as special pump/motor separation
• This shaft separation facilitates easy pump repair of pump packing, bearings, and seals without disturbing pump or motor mounting and alignment
• The SC Type coupling consists of two flanges, a sleeve and two shaft hubs

Quick Coupling Removal

• The center drop out section consists of two flanges and the flexible sleeve
• The flange is bolted to the shaft hub with four hex head cap screws
• The center drop out section can be removed by removing the hex head cap screws
• Flats on each hub provides a convenient grip for a wrench in order to facilitate loosening of the screws and, if desired, turning of the pump/motor shafts
• Once the hub is removed from the pump shaft, maintenance on the pump can be done without disturbing equipment alignment
