Diamond Products, 75029, CC7574DD 48" Diesel In-line Walk Behind Saw

In-line Walk Behind Saw with Increased Production, Lower Maintenance Costs and Better Fuel Efficiency.

Features:

Tier 4 Final Deutz diesel engine
Available with enhanced clutch assembly that allows the blade to be disengaged while the engine is running (single speed only)
Easy maneuvering self propelled drive
Strongest frame on the market
Hydraulic wheel motor drive
Blade shaft gearbox-oil bath for low maintenance
4 stage air filter system
19-3/4" maximum cutting depth
Maintenance-free DVERT diesel oxidation catalytic converter (DOC-only, no DPF).
High pressure common rail electronic fuel injection.
Modern computer interface engine controls 48" Blade Capacity

We aim to show you accurate product information. Here you will find what the manufacturers have provided us with. See our disclaimer.

Technical Details

Maximum depth of cut with 48" blade	19-3/4" (8" flange)
Motor	Deutz Turbo Diesel, Single Speed w/Clutch
Engine Specs	4 Cylinder, 3.3 Liter
Max Engine Power	74.3HP at 2,600 RPM
Power at the Blade Shaft	74 Horsepower
Emission Regulation	EPA Tier 4 Final Compliant
Blade shaft diameter	2"
Arbor size	1" w/drive pin
Blade shaft bearings	Multiple ball bearings in oil bath
Blade shaft drive	20 V-belts
Blade mounting	Right or Left
Blade raise & lower	Electro-hydraulic pump
Blade Coolant	Dual multi-spray tubes
Drive speed	0-250 feet/min forward and reverse
Transmission	Hydro pump powering dual wheel motors
Air filter	4 stage w/restriction indicator
Fuel capacity	9 gallons

Maximum depth of cut with 48" blade	19-3/4" (8" flange)
Motor	Deutz Turbo Diesel, Single Speed w/Clutch
Engine Specs	4 Cylinder, 3.3 Liter
Max Engine Power	74.3HP at 2,600 RPM
Power at the Blade Shaft	74 Horsepower
Emission Regulation	EPA Tier 4 Final Compliant
Blade shaft diameter	2"
Arbor size	1" w/drive pin
Blade shaft bearings	Multiple ball bearings in oil bath
Blade shaft drive	20 V-belts
Blade mounting	Right or Left
Blade raise & lower	Electro-hydraulic pump
Blade Coolant	Dual multi-spray tubes
Drive speed	0-250 feet/min forward and reverse
Transmission	Hydro pump powering dual wheel motors
Air filter	4 stage w/restriction indicator
Fuel capacity	9 gallons

Note: Please read description carefully. Do not base your order on the picture presented.
