| Capacity | 30 kg x 1 g (30,000 display resolution)
60 lb x 0.002 lb (30,000 display resolution) |
| Minimum Piece Weight | 30 kg (0.2 g)/60 lb (0.0005 lb) |
| Display | Three six digit 14.2 mm / 0.56" high sevensegment red LED display with three brightness levels |
| Operating Temperature | -10° C to 40° C / 14° F to 104° F |
| Power | Internal rechargeable battery giving 20 hours of use between charges. Recharge time approximately 8 hours with 12 volt UK/EU/US power adapter with center positive (included). |
| Average Working Current | < 300mA |
| Battery | 6V4A/Hr rechargeable lead-acid battery |
| Auto off | Selectable between 1 and 30 minutes or off |
| Platform Material | Stainless steel |
| Platter | 292 mm (W) x 222 mm (L) x 13 mm (H)
11.5" W x 8.75" L x 0.5" H |
| Function Keys | On/Off; Clear; Enter; Zero; Tare; Total; kg/lb; Piece Weight; PLU; Print; Currency;Upper Limit; Lower Limit and 0 – 9 for data entry. |
| Annunciators | Zero; Tare; AC Mains Connected; Battery Charging; Stable; Big Bag; Small Bag; kg and lb |
| Scale Dimension | 292 mm (W) x 333 mm (L) x 109 mm (H)
11.5" W x 13.1" L x 4.3" H |
| Keyboard Functionality | 0-9– Used for keyboard entry of piece weight, sample size, and upper and lower limit settings |
| Units/Currency | Units used to switch displayed weights between kg and lb. Currency used to switch between currency type. |
| Zero | Return displayed weight and count to zero for accurate weighing and counting. Zero range capability is 5% of scale capacity |
| Enter/Pcwt | Enter used to confirm or save entered data from keyboard. Pcwt used for keyboard entry of a known average piece weight |
| Tare | Used to zero off (up to 100% of capacity) an empty container or weight, not required in the calculation of an average piece weight. Use of tare will reduce the scales maximum weight capacity by value stored |
| Total | Ability to add the display to an accumulator (Memory +) and only accumulate when there is apercentage of weight change |
| Clear/Hi/Lo | Clear to erase a keyed in value from the display if an error has been made. Hi/Lo is to set the upper and lower limits. |
| Upper | Used to set an upper limit quantity for count check feature |
| Lower | Used to set lower limit quantity for count check feature |
| On/Off | Used to turn off display for extended battery life or reset the scale to normal weighing mode |
| Print | Output to RS-232 communications |
| Weight | 4.5 kg / 10 lb |
