| Shipped With Battery | Yes |
| How Is Battery Shipped | Shipped installed in equipment |
| Battery mAh Rating | 2450 mAh |
| Built-In Label Wizards | Breaker Box, Flags, General, Patch Panel, Pipe Marker, Safety, Sleeves, Slide, Terminal Block, Tube, Vial, Wire Wrap |
| Connectivity | Bluetooth 5 Low Energy (class II) |
| Cutter Type | Auto Cutter |
| Display Type | None |
| Keyboard Type | None |
| Memory | Memory via connected mobile device |
| Device Connectivity | Mobile device connected, PC connected |
| Number of Symbols | Dependant on software |
| Plug Type | US |
| Power Supply Voltage | 110 - 240 V |
| Auto Shut-Off / Power Conserve | User Configurable, Yes |
| Recharge Time | 2.5 hours |
| Special Characters Quantity | Determined by software |
| User Interface Type | Mobile device, PC |
| Battery Type | Internal, not removable, Lithium-ion Battery |
| RoHS Compliance Status | Compliant with Directive 2011/65/EU and 2015/863 |
| Dimensions | 3.6 in H x 6 in W x 6.4 in D |
| Weight | 2.646 lb |
| Country of Origin | Malaysia |
| Barcode Symbologies - 2D | Data Matrix, More through Brady Workstation, More through software, PDF417, QR code |
| Barcode Symbologies - Linear | Code 128, Code 128A, Code 128B, Code 128C, Code 39, Code 39 Full ASCII, Code 93, Code 93 Full ASCII, EAN-13, EAN-13 Extension 2, EAN-13 Extension 5, EAN-8, EAN-8 Extension 2, EAN-8 Extension 5, GS1-128, HIBC, Industrial 2 of 5, JAN-13, JAN-8, UPC-A, UPC-E |
| Calibration Required? | Automated through Smart Cell |
| Color Printing Capability | Single Color |
| Font Sizes | 4 - 150 pt |
| Font Styles | Determined by software |
| Label Retention Feature | Yes |
| Maximum Labels per Day | 1000 |
| Minimum Label Length | 0.240 in |
| Maximum Print Speed | 1.33 in/s |
| Minimum Liner Width | 0.813 in |
| Print Resolution | 300 dpi |
| Print Technology | Thermal Transfer |
| On Screen Indicators | Error Messaging |
| Device Drop Test and Durability | Resistant to 250-lb crushes, Resistant to 6-foot drops, Resistant to military-grade shocks (MIL-STD-810G), Sand and Dust |
| Software Package | Safety and Facility ID |
| Model | M511 |
| Color | Yellow, Black |
| Compatible Media | M4-, M4C-, M5-, M5C- |
| Label Material Types | BradyGrip Polyester, FreezerBondz Polyester, Heat-shrink Polyolefin, Metallized Polyester, Nylon Cloth, Polyester, Polypropylene, Reflective Tape, Self-laminating Polyester, Self-laminating Vinyl, StainerBondz Polyester, Tamper-resistant Vinyl, Vinyl, Vinyl Cloth, Water Dissolvable Paper |
| Materials Supported | Continuous and Die-cut |
| Maximum Label/Tape Width | 1.5 in |
| Maximum Print Width | 1.44 in |
| Maximum Printed Label Length | 39 in |
| Maximum Liner Width | 1.8 in |
| Phones and Tablets Supported | Android devices with Android OS 6+, iPhone 5S+ with iOS 10+ |
| Software Compatibility | Brady Workstation, Express Labels Mobile App, Windows based driver for 3rd party software use |
| Languages | Arabic (Egypt), Bahasa (Indonesian), Bahasa Malay, Bulgarian, Chinese (Traditional and Simplified), Croatian, Czech, Danish, Dutch, English (US), Estonian, Finnish, French (France), German, Hebrew, Hungarian, Italian, Japanese, Korean, Norwegian, Polish, Portuguese (Portugal), Romanian, Russian, Slovak, Slovenian, Spanish (universal), Swedish, Thai, Turkish, Vietnamese |
