Features:

Seamlessly connects with most existing industrial protocols for unmatched flexibility
Has built-in internal antenna, which means you don't need any external accessories to start tracking RFID-tagged goods and assets
State-of-the-art quad-core co-processors manage real-time operations without impacting the RFID performance
Industrial connectors are less prone to errors, weathering and effects of harsh conditions
With an IP67 rating, it reliably performs in harsh industrial conditions like dust, moisture and vibration
Easily install with a standard VESA 100 mounting method so there's no need for specific mounting accessories
High visibility LED bars allow you to easily see status and activity indicators in dark or bright environments

Applications:

Asset Tracking
Inventory and Inspection Labeling
RFID labeling

The powerful all-in-one Brady IRX200 RFID Reader is ready right out of the box with built-in OT and IT connections for smoother operations. Designed to withstand harsh industrial environments, it's compliant with most industrial protocols for streamlined workflows and enhanced tracking.

See more product information See less

We aim to show you accurate product information. Here you will find what the manufacturers have provided us with. See our disclaimer.

Technical Details

Reviews

Central Processing Unit (CPU)	Dual-core A53 with quad-core R5F co-CPUs
Connectivity	Ethernet, I/O connection, USB
Display Type	None
Memory	2 GB RAM, 8 GB Flash
Plug Type	None
Power Supply Voltage	24VDC, 1.25A M12-L (FE connected)
User Interface Type	None
Battery Type	No Battery
Mounting Type	4 Screws (not included), Vesa 100 wall bracket compatible
Power Requirements	Max 12W while transmit. 4W idle
Operating System	Brady by Nordic ID IoT platform, Linux
ISO Conformance Standards	ISO 18000-63 (EPC Class 1Gen2v2)
API Support	NUR API for RFID and RESTful service to access reader configuration
Integrated Antenna?	Yes
Antenna Features	Circularly polarized. Max gain +7.5dBic
Connector	RP-TNC
External Antenna Port	1 RP-TNC female with conducted power of 30dBm
Ingress Protection Rating	IP67
RoHS Compliance Status	Compliant with Directive 2011/65/EU and 2015/863
Dimensions	7.874 in H x 7.874 in W x 1.89 in D
Reading Speed	Up to 1000 tags per second
Weight	2.425 lb
Country of Origin	Finland
Device Indicators	RFID read and communication LED
Color	Blue, Gray

Notes

* Free Ground Shipping within the continental U.S. only (excludes Alaska, Hawaii, PO Boxes and APO/FPO addresses).

Product Details

Central Processing Unit (CPU)	Dual-core A53 with quad-core R5F co-CPUs
Connectivity	Ethernet, I/O connection, USB
Display Type	None
Memory	2 GB RAM, 8 GB Flash
Plug Type	None
Power Supply Voltage	24VDC, 1.25A M12-L (FE connected)
User Interface Type	None
Battery Type	No Battery
Mounting Type	4 Screws (not included), Vesa 100 wall bracket compatible
Power Requirements	Max 12W while transmit. 4W idle
Operating System	Brady by Nordic ID IoT platform, Linux
ISO Conformance Standards	ISO 18000-63 (EPC Class 1Gen2v2)
API Support	NUR API for RFID and RESTful service to access reader configuration
Integrated Antenna?	Yes
Antenna Features	Circularly polarized. Max gain +7.5dBic
Connector	RP-TNC
External Antenna Port	1 RP-TNC female with conducted power of 30dBm
Ingress Protection Rating	IP67
RoHS Compliance Status	Compliant with Directive 2011/65/EU and 2015/863
Dimensions	7.874 in H x 7.874 in W x 1.89 in D
Reading Speed	Up to 1000 tags per second
Weight	2.425 lb
Country of Origin	Finland
Device Indicators	RFID read and communication LED
Color	Blue, Gray

Note

Note: Please read description carefully. Do not base your order on the picture presented.
