| Height | 12.76 in |
| Width | 10.591 in |
| Depth | 19.291 in |
| Core Diameter | 3 in |
| Display Size | 3.5 in |
| Weight | 30.82 lb |
| Color | Blue, Gray |
| Application | Barcode Labeling, Component and Equipment Labeling, Data and Telecommunications Labeling, Electrical Labeling, General Identification, Inventory and Inspection Labeling, Laboratory Labeling, Wire and Cable Labeling |
| Shipped With Battery | Yes |
| How Is Battery Shipped | Shipped installed in equipment |
| Built-In Label Wizards | No |
| Connectivity | Ethernet, RS232, USB 2.0, USB Host |
| Cut | Auto Cutter accessory |
| Cutter Type | None |
| Device Connectivity | PC connected & Stand-alone |
| Display Type | Color LCD Screen |
| Estimated Media Changeover Time | 40 seconds |
| Keyboard Type | None |
| Media Sensor Type | Black Mark, Gap Sensor, Head Open, Notch, Reflective Sensor, Ribbon End, See-through |
| Memory | 512 MB SDRAM, 512 MB Flash |
| On-Screen Indicators | Digital Clock, Error Messaging, Ethernet Status, Ready State |
| Plug Type | US |
| Power Supply Voltage | 100 - 240 V at 50 - 60 Hz |
| Print Preview Feature? | No |
| Units | Inches, Millimeters, Points |
| User Interface Type | Buttons, PC |
| Battery Type | Internal, not removable, Lithium-manganese Battery |
| Operating System | Windows® 10, Windows® 11, Windows® Server 2019, Windows® Server 2022 |
| Type | Standard |
| Automatic Label Set Up | No |
| Barcode Symbologies - 2D | Aztec, Code 49, Composite Codes, Data Matrix, MaxiCode, MicroPDF417, PDF417, QR code |
| Barcode Symbologies - Linear | Codabar, Codablock, Code 11, Code 128, Code 39, Code 39 (Logmars), Code 49, Code 93, EAN/UPC Extension 2, EAN/UPC Extension 5, EAN-13, EAN-8, GS1 DataBar, Industrial 2 of 5, Intelligent Mail Barcode (IMb), Interleaved 2 of 5, MSI, Plessey, POSTNET, Standard 2 of 5 (IATA), UPC-A, UPC-E |
| Calibration Required? | Yes |
| Color Printing Capability | Single Color |
| Font Styles | Determined by software |
| Maximum Labels per Day | 4000 |
| Maximum Label/Tape Width | 4.488 in |
| Minimum Label Length | 0.187 in |
| Maximum Print Speed | 10 in/s |
| Maximum Printed Label Length | 8.2 ft |
| Print Resolution | 300 dpi |
| Print Technology | Direct Thermal, Thermal Transfer |
| Programming Language | ZPL Emulator |
| Media Sensor Adjustment | Yes |
| Compatible Media | 2HT-, 3HT-, APL-, DR-, DT-, HX-, LSZH-, PS-, THT-, THTEL-, XTHT-, ZH- |
| Label Material Types | Direct Thermal Paper, FreezerBondz™ Polyester, Heat-shrink Polyolefin, Metallic, Non-metal Polyester, Metallized Polyester, Metallized Polyester with Polyester Overlaminate, Nylon Cloth, Paper, Polyester, Polyimide, Polyolefin, Repositionable Paper, Self-laminating Polyester, Self-laminating Vinyl, StainerBondz™ Polyester, Static Dissipative Polyester, Tamper-evident Metallized Polyester, Tamper-evident Polyester, Vinyl, Vinyl Cloth, Water Dissolvable Paper, Water-indicating Polyester/Paper Laminate |
| Materials Supported | Bulk, Continuous, Custom, Die-cut |
| Custom Labels | Yes |
| Maximum Print Width | 4.161 in |
| Software Compatibility | Brady Workstation, Windows based driver for 3rd party software use |
| Languages | English (US), French (France), German, Korean, Spanish (universal) |
| Software Package | Product & Wire ID |
