| Height | 11 in |
| Width | 19 in |
| Depth | 14.25 in |
| Display Size | 6.11 x 3.42 in |
| Weight | 36.9 lb |
| Color | Blue, Gray |
| Application | Asset Tracking, Barcode Labeling, Cold temperature Labeling, Component and Equipment Labeling, Electrical Labeling, Exit and Egress Marking, Facility Identification, Floor Marking, Food and Beverage Process Labeling, General Identification, Hazard Communication Identification, Healthcare and Hospital Labeling, Inventory and Inspection Labeling, Lean and 5S Labeling, Pipe and Valve Marking, Safety Identification, Security Identification, Temperature Indicating Labeling, Temporary Labeling, Warehouse Marking |
| Shipped With Battery | Yes |
| How Is Battery Shipped | Shipped in box, not installed |
| Built-In Label Wizards | Arc Flash, Circle Gauge, Custom Label, General Templates, GHS/CLP, Gradient Scale, Pipe Marker, PreMade Labels, Right-to-Know, Tags, WHMIS |
| Connectivity | Bluetooth® 5 Low Energy (class II) |
| Cut | Cut at the end of print jobs, Cut between labels |
| Cutter Type | XY Cutter and Auto Cutter |
| Device Connectivity | Mobile device connected, PC connected, Stand-alone |
| Display Type | Color LCD Touch Screen |
| Estimated Media Changeover Time | 20 seconds |
| Keyboard Type | QWERTY |
| Media Sensor Type | Notch |
| Memory | 512 MB |
| Number of Symbols | 664 |
| On Screen Indicators | Bluetooth Status, Data Reception, Error Messaging, Ethernet Status, Ribbon and label part number recognition, Supply Remaining, WiFi |
| Plug Type | US |
| Power Supply Voltage | 110 - 240 V |
| Auto Shut-Off / Power Conserve | Yes |
| Print Preview Feature? | Yes |
| Special Characters Quantity | 95 |
| Units | Inches, Millimeter, Points |
| User Interface Type | Keyboard, Mobile device, PC, Touch Screen |
| Battery Type | Rechargeable Lithium-ion Battery |
| Automatic Label Set Up | Yes |
| Barcode Symbologies - 2D | More through Brady Workstation, PDF417, QR code |
| Barcode Symbologies - Linear | Code 128 Auto, Code 39, EAN-13, Interleaved 2 of 5, More through Brady WorkStation, UPC-A |
| Calibration Required? | No |
| Color Printing Capability | Multi-Color |
| Font Sizes | 4 - 600 pt |
| Font Styles | Arial, Arial 65, Courier Ne-w, MS Gothic, See Brady Workstation, Tahoma, Times Ne-w Roman, Trebuchet MS, Verdana |
| Maximum Labels per Day | 600 |
| Maximum Label/Tape Width | 4 in |
| Maximum Print Speed | 5 in/s |
| Minimum Label Length | 0.5 in |
| Maximum Printed Label Length | 8.3 ft |
| Print Resolution | 300 dpi |
| Print Technology | Thermal Transfer |
| Media Sensor Adjustment | Automatic Adjustment |
| Compatible Media | B30-, B30C-, B30EP- |
| Label Material Types | Heavy Duty Polyester, Magnetic Polyester, Metal-detectable Polyester, Metallic, Non-metal Polyester, Metallized Polyester, Paper, Phosphorescent Polyester, Polyester, Polyester with Polyester Overlaminate, Polyimide, Polyvinylfluoride, Reflective Tape, Tamper-evident Metallized Polyester, Transfer Tape, Vinyl, Vinyl Cloth |
| Materials Supported | Continuous, Die-cut |
| Maximum Print Width | 4 in |
| Software Compatibility | Brady Workstation, Express Labels Mobile App, Windows based driver for 3rd party software use |
| Languages | Bahasa (Indonesian), Bahasa Malay, Bulgarian, Chinese (Traditional and Simplified), Croatian, Czech, Danish, Dutch, English (US), Estonian, Finnish, French (France), German, Hungarian, Italian, Japanese, Korean, Norwegian, Polish, Portuguese (Portugal), Romanian, Russian, Slovak, Slovenian, Spanish (Spain), Swedish, Thai, Turkish, Vietnamese |
