| Height | 4.55 in |
| Width | 4.46 in |
| Depth | 10.97 in |
| Display Size | 3.5 in |
| Weight | 8 lb |
| Color | Blue, Gray |
| Application | Circuit Board Labeling, Component and Equipment Labeling, Data and Telecommunications Labeling, Electrical Labeling, General Identification, Wire and Cable Labeling |
| Shipped With Battery | Yes |
| How Is Battery Shipped | Shipped and installed the equipment |
| Battery mAh Rating | 2550 mAh |
| Battery Weight | 0.46 lb |
| Built-In Label Wizards | Flags, Patch Panel, Terminal Block, Wire Wrap |
| Connectivity | Bluetooth, USB, Wi-Fi |
| Cutter Type | Auto Cutter |
| Device Connectivity | Mobile device connected |
| Device Drop Test & Durability | Resistant to 4-foot drops, Resistant to military-grade shocks (MIL-STD-810G) |
| Display Type | Color Touch Screen, LCD backlit graphics display |
| Keyboard Type | None |
| Memory | 256 MB Flash, 512 MB RAM |
| Number of Symbols | Dependent on software |
| On-Screen Indicators | Battery Life, Bluetooth Status, Error Messaging, Ribbon and label part number recognition, Supply Remaining, WiFi |
| Plug Type | US |
| Power Supply Voltage | 110 - 240 V |
| Auto Shut-Off / Power Conserve | User Configurable |
| Recharge Time | 4.5 hours |
| Special Characters Quantity | Determined by software |
| User Interface Type | Mobile device, PC, Touch Screen |
| Battery Type | Rechargeable Lithium-ion Battery |
| Barcode Symbologies - 2D | Data Matrix, More through Brady Workstation, PDF417, QR code |
| Barcode Symbologies - Linear | Code 128A, Code 128B, Code 128C, Code 39, GS1 DataBar, HIBC, Interleaved 2 of 5, More through Brady WorkStation, UPC-A, UPC-E |
| Calibration Required? | Automated through Smart Cell |
| Color Printing Capability | Single Color |
| Font Sizes | Determined by software |
| Font Styles | Determined by software |
| Label Retention Feature | Yes |
| Maximum Labels per Day | 750 |
| Maximum Label/Tape Width | 2 in |
| Minimum Label Length | 0.236 in |
| Maximum Print Speed | 2.00 in/s |
| Maximum Printed Label Length | 40 in |
| Print Resolution | 300 dpi |
| Print Technology | Thermal Transfer |
| Compatible Media | BM-, BMC-, M6-, M6C- |
| Label Material Types | FreezerBondz™ Polyester, Heat-shrink Polyolefin, High Temperature Heat-shrink Polyvinylidene Fluoride Sleeve, Metallized Polyester, Metallized Polyester with Polyester Overlaminate, Nylon Cloth, Paper, Polyester, Polyethylene, Polyethylene Foam Laminate Polyester, Polyimide, Polyolefin, Polypropylene, Polyvinylfluoride, Reflective Tape, Self-laminating Polyester, Self-laminating Vinyl, StainerBondz™ Polyester, Static Dissipative Polyester, Tamper-evident Metallized Polyester, Tamper-evident Polyester, Tamper-resistant Metallized Vinyl, Tamper-resistant Vinyl, Vinyl, Vinyl Cloth |
| Materials Supported | Bulk, Continuous, Custom, Die-cut |
| Custom Labels | Yes |
| Maximum Print Width | 2 in |
| Phones & Tablets Supported | Android devices with Android OS 5+, iPhone 5S or ne+wer with iOS 10+ |
| Software Compatibility | Brady Workstation, Express Labels Mobile App, Windows-based driver for 3rd-party software use |
| Languages | Bulgarian, Chinese (Simplified), Chinese (Traditional), Croatian, Czech, Danish, Dutch, English (US), Estonian, Finnish, French (France), German, Greek, Hungarian, Italian, Japanese, Korean, Norwegian, Polish, Portuguese (Portugal), Romanian, Russian, Slovak, Slovenian, Spanish (Spain), Swedish, Turkish |
