| Height | 9.5 in |
| Width | 9 in |
| Depth | 12 in |
| Display Size | 3.5 in |
| Weight | 11.5 lb |
| Color | Blue, Gray |
| Application | Asset Tracking, Barcode Labeling, Circuit Board Labeling, Component and Equipment Labeling, Data and Telecommunications Labeling, Electrical Labeling, Facility Identification, General Identification, Hazard Communication Identification, Inventory and Inspection Labeling, Laboratory Labeling, Lean and 5S Labeling, Pipe and Valve Marking, Warehouse Marking, Wire and Cable Labeling |
| Shipped With Battery | Yes |
| How Is Battery Shipped | Shipped in a box, not installed |
| Built-In Label Wizards | No |
| Cut | Cut at the end of print jobs, Cut between labels, Full Cut |
| Cutter Type | Auto Cutter |
| Device Connectivity | PC connected |
| Display Type | Color LCD Touch Screen |
| Estimated Media Changeover Time | 15 seconds for media roll, 5 seconds for ribbon |
| Keyboard Type | None |
| Memory | 512 MB RAM, 195 MB IFFS Flash |
| Number of Symbols | See Brady Workstation Software |
| On-Screen Indicators | Data Reception, Error Messaging, Ethernet Status, Ribbon and label part number recognition, Ribbon Remaining, Supply Remaining, WiFi |
| Plug Type | US |
| Power Supply Voltage | 100 - 240 V at 50 - 60 Hz |
| Auto Shut-Off / Power Conserve | Yes |
| Print Preview Feature? | No |
| Units | Inches, Millimeters, Points |
| User Interface Type | PC, Touch Screen |
| Battery Type | Rechargeable Lithium-ion Battery |
| Operating System | Windows® 10, Windows® 11, Windows® 7, Windows® 8, Windows® Server 2012, Windows® Server 2012 R2, Windows® Server 2016 |
| Automatic Label Set Up | Yes |
| Barcode Symbologies - 2D | Aztec, Data Matrix, MicroPDF417, PDF417, QR code |
| Barcode Symbologies - Linear | Code 128A, Code 128B, Code 128C, Code 39, Code 93, EAN-13, EAN-8, HIBC, Interleaved 2 of 5, Interleaved 2 of 5 with check digit, JAN-13, JAN-8, UPC-A |
| Calibration Required? | No |
| Color Printing Capability | Single Color |
| Font Sizes | 4 - 250 pt |
| Font Styles | Arial, Courier Ne-w, Tahoma, Times Ne-w Roman, Trebuchet MS, Verdana |
| Maximum Labels per Day | 3000 |
| Maximum Label/Tape Width | 4.25 in |
| Maximum Print Speed | 4 in/s |
| Minimum Label Length | 0.25 in |
| Maximum Printed Label Length | 5 ft |
| Print Resolution | 300 dpi |
| Print Technology | Thermal Transfer |
| Programming Language | BPL (Brady Programming Language) |
| Media Sensor Adjustment | Automatic Adjustment |
| Compatible Media | B30-, B30C-, B30EP-, B33-, B33C-, B33D-, B33FP-, B33FT-, B33R- |
| Label Material Types | FreezerBondz™ Polyester, Heat-shrink Polyolefin, High Temperature Heat-shrink Polyvinylidene Fluoride Sleeve, Magnetic Polyester, Metal-detectable Polyester, Metallic, Non-metal Polyester, Metallized Polyester, Metallized Polyester with Polyester Overlaminate, Nylon Cloth, Paper, Phosphorescent Polyester, Polyester, Polyester with Polyester Overlaminate, Polyimide, Polyolefin, Polypropylene, Polyvinylfluoride, Reflective Tape, Self-laminating Polyester, Self-laminating Vinyl, StainerBondz™ Polyester, Static Dissipative Polyester, Tamper-evident Metallized Polyester, Vinyl, Vinyl Cloth |
| Materials Supported | Continuous, Custom, Die-cut |
| Custom Labels | Yes |
| Maximum Print Width | 4.015 in |
| Software Compatibility | Brady Workstation, Windows-based driver for 3rd-party software use |
| Languages | Bulgarian, Chinese (Simplified), Chinese (Traditional), Croatian, Czech, Danish, Dutch, English (US), Estonian, Finnish, French (Canada), French (France), German, Hungarian, Italian, Korean, Norwegian, Polish, Portuguese (Brazil), Portuguese (Portugal), Romanian, Russian, Spanish (Mexico), Spanish (Spain), Swedish, Thai, Turkish |
