| UOM | Kit |
| HTS Code (Harmonized Tariff Schedule) | 8443.32.1050 |
| Dimensions | 7.5 in H x 7.99 in W x 10.21 in D |
| Height | 7.5 in |
| Width | 7.99 in |
| Depth | 10.21 in |
| Display Size | 2.3 in |
| Display Size (Imperial) | 2.3 in |
| Weight | 5.07 lb |
| Application | Barcode Labeling, General Identification, Inventory and Inspection Labeling, Laboratory Labeling, Wire and Cable Labeling |
| Built-In Label Wizards | No |
| Connectivity Options | Ethernet, RS232, USB 2.0, USB Host |
| Cutter Type | None |
| Display Type | Color LCD |
| Keyboard Type | None |
| Media Sensor Type | Black Mark, Gap Sensor, Head Open, Ribbon End |
| Memory | 64 MB SDRAM;SD Flash Memory Card Reader |
| Stand Alone Printing | PC Connect |
| Mode of Operation | PC Connect |
| Plug Type | US |
| Power Supply Voltage | 100 - 240 V at 50 - 60 Hz |
| Auto Shut-Off / Power Conserve | No |
| Print Preview Feature? | No |
| User Interface Type | PC |
| Ribbon Ink Wind Direction | Ink side out |
| Supply Remaining Gauge | No |
| Automatic Label Set Up | No |
| Barcode Capability | Yes |
| Barcode Symbologies - 2D | Aztec, GS1 Data Bar, MaxiCode, Micro PDF 417, PDF 417, QR Code |
| Barcode Symbologies - Linear | Codabar;Code 11; Code 128 Subsets A,B,C; Code 128UCC; Code 39; Code 49; Code 93; EAN 8/13/128; Interleave 2 of 5;MSI; Planetcode; Plessey; PostNet; Telepen; UPC A,E |
| Color Printing Capability | Single Color |
| Maximum Labels per Day | 1000 |
| Maximum Print Speed | 4 in/s |
| Print Resolution | 300 dpi |
| Print Technology | Direct Thermal, Thermal Transfer |
| Media Sensor Adjustment | Yes |
| Label Material Types | Flame Retardant Wire Wrap;Metallized Polyester Tape;Nylon Cloth;Paper;Polyester;Polyimide;Polypropylene;Self-Laminating Vinyl |
| Continuous & Die-Cut Materials Supported | Continuous and Die-cut |
| Custom Media Parts Available | Yes |
| Maximum Label/Tape Width | 4.6 in |
| Maximum Print Width | 4.15 in |
| Maximum Printed Label Length | 450 in |
| Minimum Label Length | 0.39 in |
| Minimum Liner Width | 0.79 in |
| Maximum Liner Width | 4.6 in |
| Software Compatibility | LabelMark |
| Languages Available | Bulgarian, Chinese (Simplified), Chinese (Traditional), Czech, Danish, Dutch, English (US), Finnish, French (France), German, Greek, Hungarian, Italian, Japanese, Korean, Lithuanian, Norwegian, Polish, Portuguese (Portugal), Russian, Slovak, Spanish (Spain), Swedish, Turkish |
| RoHS Compliance Status | Please contact our CS department for more information |
