Buy Brady B33D-250-2-345, High Temp PVDF Wire Marking Sleeve

info@MegaDepot.com

(800) 884-5767
+1 (332) 900-3727 (Intl.)

Options and Related Products

Size:: Size: 0.25" Dia. x 2"
Color:: Color: White

Brady, B33D-250-2-345, 142979 0.25" Dia. x 2" White PermaSleeve High Temp PVDF Wire Marking Sleeve

PermaSleeve® Heat-Shrink Polyvinylidene Fluoride (B-345) wire marker sleeves are specifically designed for high temperature and low vacuum outgassing applications.

2:1 heat shrinkable sleeves are fade-resistant and flame-retardant, and meet the requirements of NASA Vacuum Outgassing specification SP-R-0022A
Sleeves can be used in applications that require greater resistance to harsh chemicals such as fuels, lubricants and high power cleaning solvents
Meets SAE-AMS-DTL-23053/18 (Class 2), SAE-AS-81531, MIL-STD-202, Tested per ASTM E 162, ASTM E 662; RoHS Compliant; and UL Recognized

See more product information See less

We aim to show you accurate product information. Here you will find what the manufacturers have provided us with. See our disclaimer.

Technical Details

Reviews

Unit of Measure	Roll of 500 pcs
Quantity per Roll	500
Material Number	B-345
Finish	Matte
Indoor or Outdoor Use	Outdoor Use
Maximum Service Temperature °F	437 °F
Maximum Wire Diameter	0.215 in
Maximum Wire Gauge	8 AWG
Minimum Service Temperature °F	-67 °F
Minimum Wire Diameter	0.125 in
Minimum Wire Gauge	12 AWG
Printable Sides	Double-Side Printable
Recovered Diameter	0.125 in
Roll Width	2 in
Shrink Ratio	2:1
Sleeve Size	0.25 in Dia x 2 in W
Sleeve Size(m)	6.4 mm Dia x 50.8 mm W
Sleeve Width	2 in
Trade Name	BBP 33 PermaSleeve
Applications	Cable and Wire Marking
Color	White
For Use with Printer	BBP 33 Label Printer
Label/Media Format	Roll
Label Properties	Heat Shrink Sleeves
Material	Polyvinylidene Fluoride
Material Properties	Flame-retardant, Heat-Shrinkable
Printer and Label Applications	Wire and Cable
Print Technology	Thermal Transfer
Resistance Properties	Chemical-Resistant, Corrosion-Resistant, High Temperature-Resistant, Humidity-Resistant, UV-Resistant, Weather-Resistant
Suggested Ribbon Series	R6000

Notes

* Free Ground Shipping within the continental U.S. only (excludes Alaska, Hawaii, PO Boxes and APO/FPO addresses).

Product Details

Unit of Measure	Roll of 500 pcs
Quantity per Roll	500
Material Number	B-345
Finish	Matte
Indoor or Outdoor Use	Outdoor Use
Maximum Service Temperature °F	437 °F
Maximum Wire Diameter	0.215 in
Maximum Wire Gauge	8 AWG
Minimum Service Temperature °F	-67 °F
Minimum Wire Diameter	0.125 in
Minimum Wire Gauge	12 AWG
Printable Sides	Double-Side Printable
Recovered Diameter	0.125 in
Roll Width	2 in
Shrink Ratio	2:1
Sleeve Size	0.25 in Dia x 2 in W
Sleeve Size(m)	6.4 mm Dia x 50.8 mm W
Sleeve Width	2 in
Trade Name	BBP 33 PermaSleeve
Applications	Cable and Wire Marking
Color	White
For Use with Printer	BBP 33 Label Printer
Label/Media Format	Roll
Label Properties	Heat Shrink Sleeves
Material	Polyvinylidene Fluoride
Material Properties	Flame-retardant, Heat-Shrinkable
Printer and Label Applications	Wire and Cable
Print Technology	Thermal Transfer
Resistance Properties	Chemical-Resistant, Corrosion-Resistant, High Temperature-Resistant, Humidity-Resistant, UV-Resistant, Weather-Resistant
Suggested Ribbon Series	R6000

Note

Note: Please read description carefully. Do not base your order on the picture presented.

Reviews

Brady B33D-250-2-345 High Temp PVDF Wire Marking Sleeve
