Brady Corporation, 2LSZH-125-2-RD-2, PermaSleeve Low Smoke Zero Halogen Wire Marking Sleeves

Features:

The B-7641 Heat Shrink Sleeve from Brady is a low smoke, halogen free identification material used for wire and cable identification.
Made of halogen-free, flexible flame-retardant, heat-shrinkable polyolefin tubing, offering fire safety properties and minimal smoke emission.
Compatible with the most stringent requirements in the market today to enhance fire safety needs.
2:1 heat-shrink ratio.
Use with thermal transfer printers and Brady's R6000 series halogen-free ribbon.

We aim to show you accurate product information. Here you will find what the manufacturers have provided us with. See our disclaimer.

Technical Details

Unit of Measure	Roll of 5000 pcs
Quantity per Roll	5000
Material Number	B-7641
Diameter as Supplied	0.125"
Dimensions	0.235" H
Finish	Matte
Maximum Service Temperature °F	221 °F
Maximum Wire Diameter	0.11 in
Maximum Wire Gauge	16 AWG
Minimum Service Temperature °F	-67 °F
Minimum Wire Diameter	0.062"
Minimum Wire Gauge	20 AWG
Printable Sides	Double-Side Printable
Recovered Diameter	0.062"
Recovered Wall Thickness	0.025"
Roll Width	2"
Shrink Ratio	2:1
Sleeve Size	0.125 in Dia x 1 in W
Sleeve Size(m)	3.2 mm Dia x 25.4 mm W
Sleeve Slits	Yes
Sleeve Width	1 in
Vertical Repeat	0.5 in
Web Width	3.49 in
Applications	Cable and Wire Marking, Panel Labeling
Color	Red
For Use with Printer	BBP72 Label Printer, BRADY IP Series Label Printer, BradyPrinter i5100, BradyPrinter i7100, BRADYPRINTER PR Plus Series Label Printer, THT 3" Core Printer
Label/Media Format	Roll
Label Properties	Heat Shrink Sleeves
Material	Polyolefin
Material Properties	Flame-Retardant, Heat-Shrinkable, Low-smoke, Zero-halogen
Printer and Label Applications	Wire and Cable
Print Technology	Thermal Transfer
Resistance Properties	Chemical-Resistant, Corrosion-Resistant, Humidity-Resistant, Self-Extinguishing, UV-Resistant, Weather-Resistant
Suggested Ribbon Series	R6000, R6600

Notes

* Free Ground Shipping within the continental U.S. only (excludes Alaska, Hawaii, PO Boxes and APO/FPO addresses).

Unit of Measure	Roll of 5000 pcs
Quantity per Roll	5000
Material Number	B-7641
Diameter as Supplied	0.125"
Dimensions	0.235" H
Finish	Matte
Maximum Service Temperature °F	221 °F
Maximum Wire Diameter	0.11 in
Maximum Wire Gauge	16 AWG
Minimum Service Temperature °F	-67 °F
Minimum Wire Diameter	0.062"
Minimum Wire Gauge	20 AWG
Printable Sides	Double-Side Printable
Recovered Diameter	0.062"
Recovered Wall Thickness	0.025"
Roll Width	2"
Shrink Ratio	2:1
Sleeve Size	0.125 in Dia x 1 in W
Sleeve Size(m)	3.2 mm Dia x 25.4 mm W
Sleeve Slits	Yes
Sleeve Width	1 in
Vertical Repeat	0.5 in
Web Width	3.49 in
Applications	Cable and Wire Marking, Panel Labeling
Color	Red
For Use with Printer	BBP72 Label Printer, BRADY IP Series Label Printer, BradyPrinter i5100, BradyPrinter i7100, BRADYPRINTER PR Plus Series Label Printer, THT 3" Core Printer
Label/Media Format	Roll
Label Properties	Heat Shrink Sleeves
Material	Polyolefin
Material Properties	Flame-Retardant, Heat-Shrinkable, Low-smoke, Zero-halogen
Printer and Label Applications	Wire and Cable
Print Technology	Thermal Transfer
Resistance Properties	Chemical-Resistant, Corrosion-Resistant, Humidity-Resistant, Self-Extinguishing, UV-Resistant, Weather-Resistant
Suggested Ribbon Series	R6000, R6600
