Buy Brady 2HT-250-2-BK-S-2, 129786 High Temp PVDF Wire Marking Sleeve

info@MegaDepot.com

(800) 884-5767
+1 (332) 900-3727 (Intl.)

Options and Related Products

Color:: Color: Black

Brady, 2HT-250-2-BK-S-2, 129786 0.25" Diax1" Black IP High Temp PVDF Wire Marking Sleeve

PermaSleeve Heat-Shrink Polyvinylidene Fluoride (B-345) wire marker sleeves are specifically designed for high temperature and low vacuum outgassing applications.

Features:

2:1 heat shrinkable sleeves are fade-resistant and flame-retardant, and meet the requirements of NASA Vacuum Outgassing specification SP-R-0022A
Sleeves can be used in applications that require greater resistance to harsh chemicals such as fuels, lubricants and high power cleaning solvents
Meets SAE-AMS-DTL-23053/18 (Class 2), SAE-AS-81531, MIL-STD-202, Tested per ASTM E 162, ASTM E 662;RoHS Compliant;and UL Recognized
Operating temperature range of -67 to 437° F (-55 to 225° C)
A ribbon is required to print this material. Use Part Number IP-R4400-WT for the BradyPrinter i5100 or BRADY IP Series Label Printer; use R4400-WT for a different printer

Unit of Measure	Roll
Roll of	1000 pcs

See more product information See less

We aim to show you accurate product information. Here you will find what the manufacturers have provided us with. See our disclaimer.

Technical Details

Reviews

HTS Code (Harmonized Tariff Schedule)	8443.99.2550
ECCN (Export Commodity Control Number)	EAR99
Dimensions	0.439 in H
Height	0.439 in
Roll Width	2 in
Sleeve Size	0.25 in Dia x 1 in W
Sleeve Width	1 in
Vertical Repeat	0.75 in
Recovered Diameter	0.125 in
Diameter as Supplied	0.25 in
Material Number	B-345
Material	High Temperature Heat-shrink Polyvinylidene Fluoride Sleeve
Material Properties	Flame-retardant, Heat-shrinkable
Label Properties	Heat Shrink
Finish	Matte
Color	Black
Resistance Properties	Chemical-Resistant, Corrosion-Resistant, High Temperature-Resistant, Humidity-Resistant, UV-Resistant, Weather-Resistant
Shrink Ratio	2:1
Indoor or Outdoor Use	Outdoor Use
Service Temperature Range °F	-67 °F - 437 °F
Minimum Service Temperature °F	-67 °F
Maximum Service Temperature °F	437 °F
Applications	Wire and Cable Labeling
Application	Wire and Cable Labeling
Label/Media Format	Roll
Printable Sides	Double-Side Printable
Quantity per Row	2
Sleeve Slits	Yes
Print Technology	Thermal Transfer
For Use with Printer	BBP 72 Label Printer, Brady IP Series Label Printer, BradyPrinter i5100 Industrial Label Printer, BradyPrinter i7100 Industrial Label Printer, THT 3" Core Printers
Recommended Ribbon	IP-R4400-WT, R4400-WT
Wire Diameter Range	0.125 in to 0.215 in
Wire Gauge Range	12 AWG - 8 AWG
RoHS Compliance Status	Compliant with Directive 2011/65/EU

Notes

* Free Ground Shipping within the continental U.S. only (excludes Alaska, Hawaii, PO Boxes and APO/FPO addresses).

Product Details

HTS Code (Harmonized Tariff Schedule)	8443.99.2550
ECCN (Export Commodity Control Number)	EAR99
Dimensions	0.439 in H
Height	0.439 in
Roll Width	2 in
Sleeve Size	0.25 in Dia x 1 in W
Sleeve Width	1 in
Vertical Repeat	0.75 in
Recovered Diameter	0.125 in
Diameter as Supplied	0.25 in
Material Number	B-345
Material	High Temperature Heat-shrink Polyvinylidene Fluoride Sleeve
Material Properties	Flame-retardant, Heat-shrinkable
Label Properties	Heat Shrink
Finish	Matte
Color	Black
Resistance Properties	Chemical-Resistant, Corrosion-Resistant, High Temperature-Resistant, Humidity-Resistant, UV-Resistant, Weather-Resistant
Shrink Ratio	2:1
Indoor or Outdoor Use	Outdoor Use
Service Temperature Range °F	-67 °F - 437 °F
Minimum Service Temperature °F	-67 °F
Maximum Service Temperature °F	437 °F
Applications	Wire and Cable Labeling
Application	Wire and Cable Labeling
Label/Media Format	Roll
Printable Sides	Double-Side Printable
Quantity per Row	2
Sleeve Slits	Yes
Print Technology	Thermal Transfer
For Use with Printer	BBP 72 Label Printer, Brady IP Series Label Printer, BradyPrinter i5100 Industrial Label Printer, BradyPrinter i7100 Industrial Label Printer, THT 3" Core Printers
Recommended Ribbon	IP-R4400-WT, R4400-WT
Wire Diameter Range	0.125 in to 0.215 in
Wire Gauge Range	12 AWG - 8 AWG
RoHS Compliance Status	Compliant with Directive 2011/65/EU
