Dimensions | 11 in H x 11.2 in W x 15.8 in D |
Height | 11 in |
Width | 11.2 in |
Depth | 15.8 in |
Display Size | 7 in |
Weight | 33 lb |
Application | Asset Tracking, Barcode Labeling, Circuit Board Labeling, Component and Equipment Labeling, Data and Telecommunications Labeling, Electrical Labeling, Facility Identification, General Purpose, Laboratory Labeling, Pipe and Valve Marking, Solar Panel Labeling, Wire and Cable Labeling |
Built-In Label Wizards | No |
Connectivity Options | Cabled, Ethernet, USB 2.0, USB Host |
Cut Options | Cut at the end of print jobs, Cut between labels, Full Cut |
Cutter Type | Auto Cutter |
Display Type | Color LCD Touch Screen |
Estimated Media Changeover Time | 15 seconds for media roll, 5 seconds for ribbon |
Memory | 512MB RAM;195MB IFFS |
Stand-Alone Printing | PC Connect |
Number of Symbols | See Brady Workstation Software |
Plug Type | US |
Power Supply Voltage | 100 - 240 V at 50 - 60 Hz |
Auto Shut-Off / Power Conserve | Yes |
Print Preview Feature | Yes |
Units | Inches, mm, Points |
User Interface Type | PC, Touch Screen |
Battery Type | Internal, not removable |
Operating System | Windows 10, Windows 7, Windows 8, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016 |
Supply Remaining Gauge | Yes |
Automatic Label Set Up | Yes |
Barcode Symbologies - 2D | Aztec, Data Matrix, PDF417, QR code |
Barcode Symbologies - Linear | Codabar, Code 128A, Code 128B, Code 128C, Code 39, Code 93, EAN-13, EAN-8, HIBC, Interleaved 2 of 5, JAN-8, MSI, Plessey, UPC-A |
Calibration Required | No |
Color Printing Capability | Single Color |
Font Sizes | 4 pt to 250 pt Text |
Font Styles | Arial, Courier, Tahoma, Times Roman, Trechuchet MS, TrueType fonts storable to printer, Verdana |
Maximum Labels per Day | 5000 |
Maximum Print Speed | 5 in/s |
Print Resolution | 600 dpi |
Print Technology | Direct Thermal, Thermal Transfer |
Media Sensor Adjustment | Automatic Adjustment |
On-Screen Indicators | Data Reception, Error Messaging, Ethernet Status, Ribbon and label part number recognition, Supply Remaining, WiFi |
Compatible Media | B30-, B30C-, B30EP-, B33-, B33C-, B33D-, B33FP-, B33FT-, B33R- |
Label Material Types | Vinyl, Polyester, Magnetic, Glow, Reflective, Metal Detectable, Repositionable, Paper |
Continuous and Die-Cut Materials Supported | Continuous and Die-cut |
Custom Media Parts | Yes |
Maximum Label/Tape Width | 4.25 in |
Maximum Print Width | 4.015 in |
Minimum Label Length | 0.2 in |
Minimum Liner Width | 0.71 in |
Maximum Liner Width | 4.25 in |
Software Compatibility | Brady Workstation, Windows-based driver for 3rd party software use |
Languages | Bahasa (Indonesian), Bahasa Malay, Bulgarian, Chinese (Traditional and Simplified), Croatian, Czech, Danish, Dutch, English (US), Estonian, Finnish, French (Canada), German, Hungarian, Japanese, Korean, Norwegian, Polish, Portuguese (Portugal), Romanian, Russian, Slovak, Spanish (universal), Thai, Turkish, Vietnamese |
