Automatic Label Set Up | No |
Barcode Capability | Yes |
Barcode Symbologies - 2D | Aztec, Codablock F, Data Matrix, GS1 Data Bar, Micro PDF 417, PDF 417, QR Code, RSS 14, RSS 14 Truncated, UPS MaxiCode |
Barcode Symbologies - Linear | Codabar; Code 128 Subsets A,B,C; Code 39; Code 93; EAN 8,13; EAN / UPC Appendix 2; EAN / UPC Extension 5; FIM; HIBC; Interleaved 2 of 5 Code 39; JAN 8,13; MSI; Plessey; PostNet; RSS 14; UPC A,E,E0A,E,E0 |
Calibration Required | Yes |
Color Printing Capability | Single Color |
Maximum Labels per Day | 7000 |
Maximum Print Speed | 5.9 in/s |
Print Resolution | 600 dpi |
Print Technology | Direct Thermal, Thermal Transfer |
Media Sensor Adjustment | Yes |
Label Material Types | Flame Retardant Wire Wrap; Metallized Polyester Tape; Nomex; Nylon Cloth; Paper; Polyester; Polyethylene; Polyimide; Polyolefin; Polypropylene; Push Button and Raised Panel Labels; Self-Laminating Vinyl; Tags; Tamper-Evident Metallized Polyester; Vinyl |
Continuous & Die-Cut Materials Supported | Continuous Tapes & Die-Cut Labels |
Custom Media Parts Available | Yes |
Maximum Label/Tape Width | 4.33 in |
Maximum Print Width | 4.16 in |
Minimum Label Length | 0.125 in |
Minimum Liner Width | 0.36 in |
Maximum Liner Width | 4.49 in |
Software Compatibility | Brady Workstation, LabelMark, Windows based driver for 3rd party software use |
Applications | Barcode Labeling, Circuit Board Labeling, Component and Equipment Labeling, Data and Telecommunications Labeling, Electrical Labeling, Inventory and Inspection Labeling, Laboratory Labeling, Wire and Cable Labeling |
Connectivity Options | Ethernet, RS232, USB 2.0, USB Host |
Display Type | Color Touch Screen |
Media Sensor Type | Black Mark, Gap Sensor, Notch, Reflective Sensor |
Memory | 256 MB RAM; SD Flash Memory Card Reader |
Mode of Operation | PC Connect |
Plug Type | IEC Type B |
Power Supply Voltage | 100 to 240 V at 50 to 60 Hz |
Ribbon Ink Wind Direction | Side In/Side Out |
Supply Remaining Gauge | No |
