Brady, 2HT-1000-2-WT-S, 114344 1" Diax2" White IP High Temp PVDF Wire Marking Sleeve

PermaSleeve® Heat-Shrink Polyvinylidene Fluoride (B-345) wire marker sleeves are specifically designed for high temperature and low vacuum outgassing applications.

2:1 heat shrinkable sleeves are fade-resistant and flame-retardant, and meet the requirements of NASA Vacuum Outgassing specification SP-R-0022A
Sleeves can be used in applications that require greater resistance to harsh chemicals such as fuels, lubricants and high power cleaning solvents
Meets SAE-AMS-DTL-23053/18 (Class 2), SAE-AS-81531, MIL-STD-202, Tested per ASTM E 162, ASTM E 662; RoHS Compliant; and UL Recognized
Operating temperature range is -55°F to 225°F (-48°C to 107°C)

See more product information See less

We aim to show you accurate product information. Here you will find what the manufacturers have provided us with. See our disclaimer.

Technical Details

Reviews

Unit of Measure	Roll of 100 pcs
Quantity per Roll	100
Material Number	B-345
Diameter as Supplied	1 in
Dimensions	1.66 in H
Maximum Service Temperature °F	267 °F
Maximum Wire Diameter	0.95 in
Minimum Service Temperature °F	-94 °F
Minimum Wire Diameter	0.45 in
Minimum Wire Gauge	2/0 AWG
Printable Sides	Double-Side Printable
Product Number	114344
Recovered Diameter	0.45 in
Roll Width	2 in
Shrink Ratio	2:1
Sleeve Size	1 in Dia x 2 in W
Sleeve Size(m)	25.4 mm Dia x 50.8 mm W
Sleeve Width	2 in
Trade Name	PermaSleeve
Applications	Cable and Wire Marking
Color	White
For Use with Printer	BRADY IP Series Label Printer, BradyPrinter i7100, BRADYPRINTER PR Plus Series Label Printer
Label/Media Format	Roll
Material	Polyvinylidene Fluoride
Material Properties	Heat-Shrinkable
Print Technology	Thermal Transfer
Resistance Properties	Chemical-Resistant, Corrosion-Resistant, High Temperature-Resistant, Humidity-Resistant, UV-Resistant, Weather-Resistant
Suggested Ribbon Series	R6000
Label Properties	Heat Shrink Sleeves
