Black Box, JPM612A-R8, JPM612A-R8 Includes Only:
- CAT6 Panel
- Cables Ties
- (4) 10-32
- (4) 12-24 Cuphead Screws
- Stuffer Caps
- (1) Cable Support Bar
- Manual
Features:
- Component level provides better performance and stability in the overall channel
- Includes cable management bars that make organization easier
- Designed for use in ETL-Verified GigaTrue® channel
- Meets or exceeds ANSI/TIA/EIA-568-C CAT6 component performance
Component level tested panel that provides better performance and stability in the overall channel; the panel by itself can pass CAT6
Includes cable management bars that make organization easier
Meets or exceeds ANSI/TIA/EIA-568-C.2 Category 6 component performance specifications
Tested for NEXT, Power Sum NEXT, FEXT, Return Loss and attenuation to 250 MHz
Universal wiring - panel is supplied with labeling for both T568A and T568B
Paired punchdown sequence enables pair twist within 1/2" of termination
Redesigned IDC 110 block features peaks to make lacing cable easier
Rolled-edge construction provides superior panel rigidity to eliminate flex during termination
