General |
Console Management | Built-in web terminal, SSH direct to consoles, optional console keystroke logging, alert on cable disconnects, text pattern match and more, inline power control, multiple concurrent sessions |
Emissions | FCC Part 15 Subpart B Class A; ICES-003 Issue 4 February 2004; AS/NZS CISPR 22: 2004 Class A; EN 55022 Emissions Class A (2009) A1 (2010); EN 61000-3-2 Harmonics Current Emissions (2014); EN 61000-3-3 Voltage Fluctuation and Flicker (2013) |
Humidity | 5 to 90% |
Immunity | Immunity: EN 55024 ITE Immunity (2010); IEC 61000-4-2 (2008); IEC 61000-4-3 (2006) A1 (2007) A2 (2010); IEC 61000-4-4 (2012); IEC 61000-4-5 (2014); IEC 61000-4-6 (2013); IEC 61000-4-8 (2009); IEC 61000-4-11 (2004) |
Interface | Ethernet Ports: (2) 10-/100-/1000-Mbps Ethernet/SFP fiber ports with 1500 VAC isolation and ESD protection; Console Port: (1) RJ-45 RS-232 console port: WiFi: 802.11 a/b/g/n, AP or Client mode, Infrastructure or AD-hoc,WEP, WPA-PSK, WPA2-PSK, WPA-None, WPA-PEAP-MSCHAPv2; Encryption: TKIP, AES; PSTN Modem: (1) internal V.92 modem with RJ-11 socket; Serial Ports: Software-selectable, 50 to 230,400 bps USB: (2) USB 3.0 ports for increased storage Remote Access: Integrated 4G LTE Cellular Card, integrated V.92 PSTN dial-in, dual Ethernet, aggregation; and redundancy, remote access automatic network failover, easy browser UI IPv6 |
Memory | 256 MB DDR2 SDRAM; 64 MB Embedded NOR Flash |
Modem Support | (1) internal V.92 modem with RJ-11 socket |
Power | Dual AC socket, universal 100–240 VAC |
Power Consumption | Less than 30 W |
Security and Authentication | SSH; FIPS-140-2 compliant Open SSL Module; Strong ciphers—AES encryption; Cisco-compatible IPsec; AAA—TACACS+, RADIUS, Active Directory/OpenLDAP, Kerberos, with local fallback; Two factor authentication via remote AAA; Configurable stateful firewall; OpenVPN |
Serial Port Signals | (1) RJ-45 RS-232 console port |
Storage temperature | -20 to +140° F (-30 to +60° C) |
Mechanical |
Connectors | (8) RJ-45 RS-232 software-selectable console ports; (2) Ethernet R10/100/1000 Ethernet RJ-45/SFP; (1) RJ-45 RS-232 console port; (2) USB 3.0 ports |
Dimensions | 1.75"H x 17"W x 10"D (4.5 x 44 x 25.4 cm) |
Weight | 10 lb. (4.5 kg) |
Operating Environment |
Temperature | 41 to 122° F (5 to 40° C) |
