Buy BlackBox IC190C-R2, RS-232 PCI Card, 8-Port, Low Profile, 16854 UART

info@MegaDepot.com

(800) 884-5767
+1 (332) 900-3727 (Intl.)

RS-232 PCI Card, 8-Port, Low Profile, 16854 UART

Quick Facts

Supports all PCI interrupts. You have more IRQs and fewer installation problems!
Universal bus compatible-operates in 5-V or 3.3-V signaling level systems!

Further Details

Provides up to 8 PCI bus links for communication servers, point-of-sale (POS) systems, and other RS-232 devices.
16854 UART eliminates data bottlenecks and enables your CPU's onboard serial ports to achieve 460.8-kbps sustained data rates.
Compatible with all Windows® operating systems (Oss) as well as Linux® and QNX. Includes drivers for Windows diagnostics and other enhanced features.
Includes an ISP port for IRQ sharing.
Features a low profile.

We aim to show you accurate product information. Here you will find what the manufacturers have provided us with. See our disclaimer.

Technical Details

Distance (Maximum)	50 ft. (15.2 m)
Protocol	Asynchronous
Speed (Maximum)	460.8 kbps (sustained)
CE Approval	Yes
Connectors	(1) DB78 F on card; (1) DB78 F and (8) DB25 M on included octopus cable

Distance (Maximum)	50 ft. (15.2 m)
Protocol	Asynchronous
Speed (Maximum)	460.8 kbps (sustained)
CE Approval	Yes
Connectors	(1) DB78 F on card; (1) DB78 F and (8) DB25 M on included octopus cable

Note: Please read description carefully. Do not base your order on the picture presented.
