VELAB VE-D300 Digital Biological Binocular Microscope

  • Brand VELAB
  • Part # VE-D300
  • Condition
    Brand New
  • Manufacturer List Price
    $3,628.00
Availability
Typically In Stock
Check Availability
Quantity
Share:

VELAB, VE-D300, Digital Biological Binocular Microscope with Plan Achromatic Objectives

VE-D300 Includes Only:

  • Dust cover.
  • Immersion oil.
  • Power cord.
  • Software CD.
  • USB cable.

The VE-D300 digital microscope was designed for professional use. It has all the virtues of a professional biological microscope, in addition to being equipped with a 5.0MP digital camera. It includes an easy-to-use software compatible with Windows operating systems, practical for editing, storing and observing images in real time. It can perform measurements in a wide range of units. Compatible with Windows 10 and lower operating systems. The VE-D300 is ideal for the identification and analysis of biological samples in areas such as biology, medicine, pathology and microbiology. Adaptable to the needs of the user, the VE-D300 offers optional configurations for several applications.

Features:

  • Diopter adjustment in both eyepieces.
  • Interpupillary distance of 50 - 75 mm.
  • Heads inclined at 30°.
  • Stative, robust and reinforced. Easy to transport.
  • Plates with vernier, millimeter scale and calipers.
  • Objectives with colored rings.
  • Lighting with intensity adjustment.
See more product information See less

We aim to show you accurate product information. Here you will find what the manufacturers have provided us with. See our disclaimer.

Authorized Distributor

Technical Details

Reviews
Subject to the use of all the optional accessories
Eyepieces:PL 10X/20 mm with rubber eyecups and ± 5 mm diopter adjustment in both Eyepieces.
Head:Binocular Siedentopf type, 30 degree inclined with interpupillary distance adjustment between 50 - 75 mm/1.96"- 2.95" and integrated 5.0MP digital camera.
Nosepiece:Quadruple Nosepiece with anti-slip grip and click-stops, mounted on high-tension ball bearings.
Objectives:4X, 10X, 40X (S) and 100X (S) (oil), infinity corrected plan achromatic optics and color ring for easy identification
Stand:Stative, robust and reinforced with epoxy paint finish.
Stage:Two-Layer Stage with X-Y coaxial movement, 5.90" x 5.51", vernier, millimeter scale (3.46" x 2.36"), clamp and height adjustment with stop.
Condenser:Abbe, N.A. 1.25 with height adjustment screw. Equipped with an adapter for optional configurations (not included).
Diaphragm:Iris with filter holder.
Focusing:Coarse and fine anti-slip control knob with 0.001 mm precision, 200 graduations per micrometer turn (0.2 mm) and tension adjustment.
Illumination:3W Kohler LED with intensity control and field Diaphragm in the lamp.
Power Supply:110-240V, 50/60 Hz, AC Adapter.
Dimensions:8.07" x 18.42" x 14.96"
Product Details
Subject to the use of all the optional accessories
Eyepieces:PL 10X/20 mm with rubber eyecups and ± 5 mm diopter adjustment in both Eyepieces.
Head:Binocular Siedentopf type, 30 degree inclined with interpupillary distance adjustment between 50 - 75 mm/1.96"- 2.95" and integrated 5.0MP digital camera.
Nosepiece:Quadruple Nosepiece with anti-slip grip and click-stops, mounted on high-tension ball bearings.
Objectives:4X, 10X, 40X (S) and 100X (S) (oil), infinity corrected plan achromatic optics and color ring for easy identification
Stand:Stative, robust and reinforced with epoxy paint finish.
Stage:Two-Layer Stage with X-Y coaxial movement, 5.90" x 5.51", vernier, millimeter scale (3.46" x 2.36"), clamp and height adjustment with stop.
Condenser:Abbe, N.A. 1.25 with height adjustment screw. Equipped with an adapter for optional configurations (not included).
Diaphragm:Iris with filter holder.
Focusing:Coarse and fine anti-slip control knob with 0.001 mm precision, 200 graduations per micrometer turn (0.2 mm) and tension adjustment.
Illumination:3W Kohler LED with intensity control and field Diaphragm in the lamp.
Power Supply:110-240V, 50/60 Hz, AC Adapter.
Dimensions:8.07" x 18.42" x 14.96"
Note

Note: Please read description carefully. Do not base your order on the picture presented.
