REED Instruments R2300 Infrared Thermometer, 12:1, 752F, 400C

Calibration: without NIST
  • Condition
    Brand New

Contact Us For Pricing

Availability
Contact Us
Check Availability
Quantity
Share:

Options and Related Products

Calibration:
Calibration: without NIST

R2300 Includes Only:

  • Infrared Thermometer
  • Battery

Features:

  • Built-in laser pointer identifies target area
  • User selectable °F or °C
  • 12:1 distance to spot size ratio
  • Digitally adjustable emissivity
  • Max and Min readings
  • Backlit display
  • High and low alarms
  • Low battery indication and auto shut off

Applications:

  • Verify mechanical (bearings, motors) or electrical (circuit breaker boxes) equipment
  • Calibration and control of heater and oven temperatures
  • Monitoring materials in processes involving heating and/or cooling
  • Quality control monitoring
  • Research and development applications
  • Automotive diagnostics
  • Conduct HVAC/R energy audits

This infrared thermometer features a 12:1 distance to spot ratio and is capable of measuring temperatures up to 752°F (400°C). The R2300 is an affordable non-contact measurement solution able to quickly and efficiently measure the temperature of hot, hazardous or hard-to reach objects from a safe distance.

    See more product information See less

    We aim to show you accurate product information. Here you will find what the manufacturers have provided us with. See our disclaimer.

    Authorized Distributor

    Technical Details

    Optional Accessories
    Reviews
    Temperature Range-25.6 to 752°F (-32 to 400°C)
    Accuracy±4°F (2°C) or ±2% rdg.
    Resolution0.1°F (0.1°C)
    Optical Resolution (D:S)12:1
    Spectral Response8 to 14µm
    Emissivity0.1 to 1.0 (Adjustable)
    Response Time500ms
    Backlit DisplayYes
    Display HoldYes
    High/Low AlarmsYes
    Alarm IndicatorsYes (Beeping)
    Max/MinYes
    F/C SwitchableYes
    Laser TypeClass II
    Low Battery IndicatorYes
    Power Supply9V Battery
    Product CertificationsCE, ETL, RoHS
    Battery LifeApprox. 10 hours (with continuous use, backlight on)
    Storage Temperature-4 to 140°F (-20 to 60°C)
    Operating Humidity Range<90%
    Maximum Operating Altitude6561' (2000m)
    Maximum Storage Altitude39370' (12000m)
    Dimensions6.0" x 4.3" x 1.6" (153 mm x 108 mm x 40 mm)
    Weight6.5 oz / (185 g.)
    Notes

    * Free Ground Shipping within the continental U.S. only (excludes Alaska, Hawaii, PO Boxes and APO/FPO addresses).

    Product Details
    Temperature Range-25.6 to 752°F (-32 to 400°C)
    Accuracy±4°F (2°C) or ±2% rdg.
    Resolution0.1°F (0.1°C)
    Optical Resolution (D:S)12:1
    Spectral Response8 to 14µm
    Emissivity0.1 to 1.0 (Adjustable)
    Response Time500ms
    Backlit DisplayYes
    Display HoldYes
    High/Low AlarmsYes
    Alarm IndicatorsYes (Beeping)
    Max/MinYes
    F/C SwitchableYes
    Laser TypeClass II
    Low Battery IndicatorYes
    Power Supply9V Battery
    Product CertificationsCE, ETL, RoHS
    Battery LifeApprox. 10 hours (with continuous use, backlight on)
    Storage Temperature-4 to 140°F (-20 to 60°C)
    Operating Humidity Range<90%
    Maximum Operating Altitude6561' (2000m)
    Maximum Storage Altitude39370' (12000m)
    Dimensions6.0" x 4.3" x 1.6" (153 mm x 108 mm x 40 mm)
    Weight6.5 oz / (185 g.)
