NOVUS, 8104211400, N1040-PRAR 100-240VAC/DC Temperature Controller, 2 Relay, Pulse Output, Analog Output, 48x48 mm
Features:
- Auto-tuning of PID parameters
- Silicone rubber frontal keypad
- The outputs are programmable for the main control or alarm
- Two alarm functions can be directed to a single output
- A very efficient universal switching power supply provides high accuracy conditions even during mains voltage
- Safe output function allows the user to set control output conditions in case of sensor break or failure
- LBD (Loop Break Detection) function detects failures in the control loop
- Simplified programming menu makes operator programming very easy
- An indelible electronic serial number with 8 digits can be accessed from the display
- Keypad protection prevents unauthorized programming changes
The N1040 Temperature Controller is a cost-effective, high-performance solution designed for precise temperature control in a variety of applications. Featuring a compact 1/16 DIN design, it supports universal inputs including thermocouples (J, K, T) and Pt100 RTD without the need for hardware changes. With auto-tuning PID, multiple configurable outputs, and advanced alarm functions, the N1040 ensures reliable and accurate performance. Its robust construction, including IP65 front panel protection, makes it suitable for harsh environments, while the removable wiring connection block simplifies installation.
