| Video compression | H.265 Pro+/H.265 Pro/H.265/H.264+/H.264 |
| Encoding resolution | - For 4 MP stream access: 4 MP lite at15fps; 1080p lite/720p/WD1/4CIF/VGA/CIF at25fps (P)/30fps (N)
- For 3 MP stream access: 3 MP/1080p/720p/VGA/WD1/4CIF/CIF at15fps
- For 1080p stream access: 1080p/720p at15fps; VGA/WD1/4CIF/CIF at25fps (P)/30fps (N)
- For 720p stream access: 720p/VGA/WD1/4CIF/CIF at25fps (P)/30fps (N)
- 5 MP lite/4 MP lite/3 MP at15fps; 1080p lite/720p lite/VGA/WD1/4CIF/CIF at25fps
|
| Frame rate | - For 4 MP stream access: 4 MP lite at15fps; 1080p lite/720p/WD1/4CIF/VGA/CIF at25fps (P)/30fps (N)
- For 3 MP stream access: 3 MP/1080p/720p/VGA/WD1/4CIF/CIF at15fps
|
| Sub-stream: WD1/4CIF at12fps; CIF at25fps (P)/30fps (N) |
| Video bit rate | 32 Kbps to 6 Mbps |
| Dual stream | Support |
| Stream type | Video, Video & Audio |
| Audio compression | G.711u |
| Audio bit rate | 64 Kbps |
| AHD input | 4 MP, 1080p25, 1080p30, 720p25, 720p30 |
| HDCVI input | 4 MP, 1080p25, 1080p30, 720p25, 720p30 |
| CVBS input | PAL/NTSC |
| VGA output | 1-ch, 1920 x 1080/60Hz, 1280 x 1024/60Hz, 1280 x 720/60Hz, 1024 x 768/60Hz |
| HDMI output | 1-ch, 4K (3840 x 2160)/30Hz, 2K (2560 x 1440)/60Hz, 1920 x 1080/60Hz, 1280 x1024/60Hz, 1280 x 720/60Hz, 1024 x768/60Hz |
| Audio input | 1-ch, RCA (2.0 Vp-p, 1 KΩ) |
| Audio output | 1-ch, RCA (Linear, 1 KΩ) |
| Two-way audio | 1-ch, RCA (2.0 Vp-p, 1 KΩ) (using the first audio input) |
| Network protocol | TCP/IP, PPPoE, DHCP, LTS-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™,HTTPS, ONVIF |
| Network interface | 1, RJ45 10M/100M self-adaptive Ethernet interface |
| SATA | 2 SATA interfaces |
| Capacity | Up to 10 TB capacity for each disk |
| Serial interface | RS-485 (half-duplex) |
| USB interface | 2 x USB 2.0 |
| Power supply | 12 VDC |
| Dimension (W x D x H) | 380 x 320 x 48 mm (15.0 x 12.6 x 1.9 inch) |
