EL-USB-ACT Includes Only:
- AC and DC Millivolt Data Logger
- 2 pc Battery
- USB cable
When used with a current clamp, this standalone data logger measures and stores up to 127,232 a.c. and d.c. current readings over a 0 to 1000A d.c. measurement range (0 to 723A for a.c.). In energy monitoring mode, this data is converted into power, energy (using a user defined voltage value) and cost (using a user supplied energy unit cost). The millivolt measurement mode allows for direct measurement of voltage, up to 1V d.c. (700mV a.c.).
The user can easily set up the logger and view downloaded data by plugging the data logger into a PCs USB port and using the free software. The software has provision for a clamp scaling factor (the clamp input-output ratio of amps to millivolts). Stored data can then be graphed, printed and exported to other applications. The high contrast LCD can show a variety of current, power, energy and cost information. At the touch of a button, the user can cycle between the most recent, maximum and minimum measurement values
Features:
- Energy monitoring mode (to calculate power, cumulative energy and cumulative cost)
- Compatible with a.c. and d.c. current clamps
- A.c. and d.c. millivolt measurement mode
Application:
- Outside Environmental Data
- Facilities Management
