Flowline 300500 DataKeep Explosion Proof Level Indicator

  • Brand Flowline
  • Part # 300500
  • Model # DataKeep
  • Condition
    Brand New

Contact Us For Pricing

Availability
Contact Us
Check Availability
Quantity
Share:

DataKeep Explosion Proof Level Indicator

Features:

  • Aluminum XP windowed enclosure with dual conduitports.
  • LCD display indicates engineering units anddescriptors.
  • Non-volatile memory with security password.
  • SafeTouch through-glass button programming.
  • 32-point, square root or exponential linearization.

Application:

The explosion proof loop powered level indicator displays engineering units connected in series with one 4-20 mA continuous level transmitter. Select this level indicator for hazardous applications with an explosion proof level sensor. The windowed field enclosure is easily wall mounted and includes two conduit connectors.

See more product information See less

We aim to show you accurate product information. Here you will find what the manufacturers have provided us with. See our disclaimer.

Authorized Distributor

Technical Details

Reviews

Display Type:

Upper: LCD 5 digits, Lower: 7 characters
Display Units:Engineering
Display Output:0.001 to 99,999
Display Height:Main: 0.70" (18mm) Secondary: 0.4" (10mm)
Decimal Point:0, 1, 2 or 3
Configuration:Push button / SafeTouch through-glass
Memory:Non-volatile
Sensor Input:(1) 4-20 mA transmitter
Loop Power:9-30 VDC
Voltage Drop:3.0 VDC @ 20 mA
w/o loop-powered backlight
6.0 VDC @ 20 mA
with loop-powered backligh
Ambient Temp.:F: -40° to 167°, C: -40° to 75°
Enclosure Rating:NEMA 4X, 7 & 9 (IP68)
Enclosure Mat'l.:Aluminum
Window Mat'l.:Glass
Conduit Entrance:Dual, 3/4" NPT
Classification:Explosion proof
Compliance:CE
Approvals:FM, ATEX, IECEx, CSA
Product Details

Display Type:

Upper: LCD 5 digits, Lower: 7 characters
Display Units:Engineering
Display Output:0.001 to 99,999
Display Height:Main: 0.70" (18mm) Secondary: 0.4" (10mm)
Decimal Point:0, 1, 2 or 3
Configuration:Push button / SafeTouch through-glass
Memory:Non-volatile
Sensor Input:(1) 4-20 mA transmitter
Loop Power:9-30 VDC
Voltage Drop:3.0 VDC @ 20 mA
w/o loop-powered backlight
6.0 VDC @ 20 mA
with loop-powered backligh
Ambient Temp.:F: -40° to 167°, C: -40° to 75°
Enclosure Rating:NEMA 4X, 7 & 9 (IP68)
Enclosure Mat'l.:Aluminum
Window Mat'l.:Glass
Conduit Entrance:Dual, 3/4" NPT
Classification:Explosion proof
Compliance:CE
Approvals:FM, ATEX, IECEx, CSA
Note

Note: Please read description carefully. Do not base your order on the picture presented.
