Dwyer MMA-19-LV Flowmeter 0.1-0.5 LPM Air without Configurable Valve

Range: 0.1-0.5 LPM Air, without Configurable Valve
  • Brand Dwyer
  • Part # MMA-19-LV
  • Condition
    Brand New

Contact Us For Pricing

Availability
Contact Us
Check Availability
Quantity
Share:

Options and Related Products

Range:
Range: 0.1-0.5 LPM Air, without Configurable Valve

Dwyer, MMA-19-LV, Flowmeter, Range 0.1-0.5 LPM Air, without Configurable Valve

Features:

  • Low installation costs with easy mounting
  • Long operation life with durable construction
  • Precision molding enables high repeatability
  • White back on the flow tube allows for better visibility of the float increasing readingaccuracy
  • Side printed scale graduations allows for instantaneous flow reading saving time
  • Compact bodies require minimal panel space freeing valuable space

Applications:

  • Medical equipment
  • Air samplers
  • Gas analyzers
  • Pollution monitors
  • Chemical injectors
  • Cabinet purging

The Series MM Mini-Master ® Flowmeters consists of two series of flowmeters suitable for both gas and liquid applications with advanced features at a low cost. The Series MMA is a 2" (51 mm) scale flowmeter that is user configurable with or without non-removable top or bottom front mounted metering valves. It is constructed from transparent nylon material providing high chemical resistance and is easily disassembled via the provided key for cleaning or reconfiguration. The Series MMF is a 1-1/2" (38 mm) scale compact flowmeter ideal for measuring small volume air. It features bezel type mounting that can be quickly installed from the front of the instrument panel.

See more product information See less

We aim to show you accurate product information. Here you will find what the manufacturers have provided us with. See our disclaimer.

Authorized Distributor

Technical Details

Reviews
Accuracy± 4 %
ApplicationsIndustrial and Manufacturing, OEM, Pneumatic Systems
ComplianceRoHS 2
Compliance NoteMeets the technical requirements of EU Directive 2011/65/EU (RoHS II)
Gas Flow, Max0 m³/s
Liquid Flow, Max0.5 l/min
Liquid Flow, Min0.1 l/min
Material Construction OptionN/A
Materials, WettedBuna-N (NBR), Nylon 12, Stainless Steel
Media CompatibilityAir, Water
Operating Temperature, Max130 °F
Process Connection Note5/16" OD for push on rubber or plastic tubing with provided spring tubing clamp. Connect to rigid tubing with double compression fitting
Process Connection Size5/16 in
Process Connection TypeBarbed Fitting
Proof PressureUp to 50 psi
Scale Length2 in
Scale Media CalibrationWater
Valve TypeWithout Configurable Valve
Weight1 oz
Notes

* Free Ground Shipping within the continental U.S. only (excludes Alaska, Hawaii, PO Boxes and APO/FPO addresses).

Product Details
Accuracy± 4 %
ApplicationsIndustrial and Manufacturing, OEM, Pneumatic Systems
ComplianceRoHS 2
Compliance NoteMeets the technical requirements of EU Directive 2011/65/EU (RoHS II)
Gas Flow, Max0 m³/s
Liquid Flow, Max0.5 l/min
Liquid Flow, Min0.1 l/min
Material Construction OptionN/A
Materials, WettedBuna-N (NBR), Nylon 12, Stainless Steel
Media CompatibilityAir, Water
Operating Temperature, Max130 °F
Process Connection Note5/16" OD for push on rubber or plastic tubing with provided spring tubing clamp. Connect to rigid tubing with double compression fitting
Process Connection Size5/16 in
Process Connection TypeBarbed Fitting
Proof PressureUp to 50 psi
Scale Length2 in
Scale Media CalibrationWater
Valve TypeWithout Configurable Valve
Weight1 oz
