Dixon Valve SF420FGXFGCS10 4" Split Flange Swivel Style 20 FGxFG CS, Viton Seals

4" Split Flange Swivel Style 20 FGxFG CS, Viton Seals

Applications:

• For use in industries from petroleum, blending plants, petrochemical, refining, mining, distilling, paint plants, farm irrigation and fertilizing, wastewater treatment, food and beverage process equipment, marine and many more

Features:

• Bearing pack design allows easy seal change without removing the ball bearings.
• Simple maintenance: remove one nose piece, replace seal pack, and reinstall with little down-time.
• Instream seal separates the wetted area from the ball bearings allowing for longer bearing pack life over conventional swivels.
• Wide set bearing race for higher moment loads
• Compact design for low profile applications

Construction:

• Bearing pack: through hardened forged high carbon alloy
• Material contact surfaces: stainless steel or carbon steel nose pieces

Available Options:

• All styles
• Stock end configurations: 150 Ib. and 300 Ib. flanges, FNPT, butt weld, others per request
• Stock seals: Baylast™, FKM, PTFE, others per request
• Full penetration weld

Safety notes:

• WARNING: This product contains a chemical known to the State of California to cause birth defects or other reproductive harm. Do not use in connection with drinking water. Wash hands after handling.
