Dixon Valve 4DS4-B-SV F-Series 1/2" x 1/2" Coupler, Steel Valve

Dixon Valve, 4DS4-B-SV, F-Series 1/2" x 1/2" Pneumatic Automatic Standard Hose Barb Coupler, Brass, Steel Valve

Features:

• Machined components are manufactured using solid bar stock.
• Nitrile (Nitrile Rubber) seals are standard.
• Compatibility and Interchange Data: Foster 3, 4, 5 and 6 Series, Parker 30 - Series Automatic Interchange, Hansen 3000, 4000, 5000 and 6000.
• Connected brass coupler and steel plug
• 500 PSI (35 bar) Maximum Working and 14,000 PSI (965 bar) Burst

Note:

• It is important to be safe when installing quick disconnect couplings into a pneumatic circuit.
• It is important to be safe when installing quick disconnect couplings into a pneumatic circuit. Never install a pneumatic coupling directly into an air tool, use a piece of hose that is at least 18" long, between the tool and the coupling, to prevent damage to the coupling. To protect the operator, safety devices, such as a safety check valve and safety cable should be installed in case there is a hose or coupling failure.
• Operating pressure for couplings utilizing hose barb connections may be dramatically reduced to that of the hose rating and/or hose end connection combination. Consult hose manufacturer's catalog for hose end connection ratings. If in doubt, test under controlled conditions for suitability to application.
• Dixon cannot assume liability for misapplication of production resulting in equipment down-time, lost production, and/or personal injury including death.

Constructions:
