Cecomp Electronics Series F16ADABL Programmable Digital Pressure Gauge

Features:

• ±0.25% Test Gauge Accuracy
• 316L Stainless Steel Wetted Parts
• ADA: Dual Programmable Alarms
• Low Voltage Powered

Cecomp Digital Pressure Gauge with Programmable Alarms Series F16ADABL. Programmable dual form C (SPDT) relay contacts for HI/LO, HI/HI, LO/LO, normal or reverse acting with 1% deadband, or adjustable trip and reset points for each relay, manual or auto acknowledge. 1A/24VDC, 0.5A/115VAC, non-inductive 120 milliseconds typical response time. Extruded aluminum case, epoxy powder coated, ABS/ polycarbonate bezel, front and rear gaskets, polycarbonate label. 4 readings per second nominal display update rate. Accuracy includes linearity, hysteresis, repeatability. Red LED backlight on when gauge is on Alarm 1 and Alarm 2 LCD indicators and bi-color (red/green) LEDs.

For more information, please see Data Sheet
