AR North America MEC8000 Battioni Pagani Rotary Vane Vacuum Pump

  • Brand AR North America
  • Part # MEC8000
  • Model # Battioni Pagani
  • Condition
    Brand New

Contact Us For Pricing

Availability
Contact Us
Check Availability
Quantity
Share:

AR North America, MEC8000, Battioni Pagani 2139,79 Geometric Capacity GPM Rotary Vane Vacuum Pump

The Battioni Pagani series of industrial rotary vane vacuum pumps have been used for many years to empty cesspools, transport sewage and in agricultural fertilizing irrigation operations. They have an excellent reliability.

See more product information See less

We aim to show you accurate product information. Here you will find what the manufacturers have provided us with. See our disclaimer.

Authorized Dealer

Technical Details

Reviews
Weight353
Max RPM600 / 1400
Pump TypeP LA DX UL D76 EM
Pump Types DescriptionP-Driven through Pulley or Belts / LA-Auto Lubrication / DX-Clock Wise Rotation / UL-2 Port 2 Revolving Elbows / D76-2 Port - 3" Elbow
Max Absolute (reletive) Pressure36.26
Geometric Capacity GPM2139.79
Vacuum without depression Valve Fitted PSI-13.63
Power absorption Max Vacuum HP36.2
Power absorption 36.6 PSI absolute 1400 rpm HP16.9
L/min.8100
Cubic feet/min. CFM286
Product Details
Weight353
Max RPM600 / 1400
Pump TypeP LA DX UL D76 EM
Pump Types DescriptionP-Driven through Pulley or Belts / LA-Auto Lubrication / DX-Clock Wise Rotation / UL-2 Port 2 Revolving Elbows / D76-2 Port - 3" Elbow
Max Absolute (reletive) Pressure36.26
Geometric Capacity GPM2139.79
Vacuum without depression Valve Fitted PSI-13.63
Power absorption Max Vacuum HP36.2
Power absorption 36.6 PSI absolute 1400 rpm HP16.9
L/min.8100
Cubic feet/min. CFM286
Note

Note: Please read description carefully. Do not base your order on the picture presented.
