Across, G04h, Ai RapidChill 4 CF -86°C Stackable Ultra Low Freezer UL 110V

G04h Includes Only:

Ai G04h -86°C ultra-low upright freezer - 1 pc
Remove-able shelf - 1 pc
Door and control panel key - 2 sets
Ice Scrapper - 1 pc
User's manual - 1 pc

The Ai RapidChill series -86C ultra-low upright ULT freezers is designed for fast cooling, ultra-low power consumption, very low noise, and ease of maintenance. All RapidChill ultra-low freezers are UL certified.

Features:

CDC and VFC compliant, great for storage of Covid-19 vaccines, DNA, RNA, virus samples, organs, and serum
State-of-the-art Vacuum Insulated Panel (VIP, Micro-Cellular Polyurethane) insulated
Safe, environmentally friendly, energy efficient, and easy-to-acquire HC refrigeration system
Remote alarm, RS-485
Door lock, high or low temperature alarms, power failure alarm, door open alarm, filter clogging alarm, password protection, tons of security features to protect you, your products, and the unit
Digital temperature display with microprocessor-based temperature controller
All stainless steel interior for clean operation, durability, and ease of maintenance
Dual silicon sealing gaskets for ultra airtight operation
48-hour battery backup for controller and alarm
Extremely quiet and reliable
Built-in swivel casters with leveling feet
Compliant to UL 61010-1 and CSA C22.2 standards

See more product information See less

We aim to show you accurate product information. Here you will find what the manufacturers have provided us with. See our disclaimer.

Technical Details

Reviews

Electrical requirements

110V (+/-10%) 60Hz 1-Phase 680W 6A

Power consumption

5.5 kW/day

Performance

Temperature range: -40°C to -86°C
Time from ambient to -86°C: 4 hours
Uniformity: ±4°C
Time from -86°C to -50°C with door close (ambient 25°C): 2 hours

Controller

Style: microcomputer controlled with analog display
Range -40°C to -86°C
Step: 1°C
Thermo sensor: PT100
Displays: internal temperature, ambient temperature, input voltage, error code
Indicators: Locked, running, power, alarm, door open, over temperature battery low, condenser clean

Compressor

Make: SECOP (formerly known as Danfoss), Germany
Style: direct cooling
Power: 115V 60Hz 1-PHASE, 0.54HP
Number of compressors: one
HC refrigerants: R600A, R1150 and R50

Chamber

Dimensions: 13 x 19.5 x 24.5" (WxDxH)
Material: powder coated steel
Effective capacity: 3.5 Cu Ft
Insulation: VIP (Vacuum Insulated Panel)

Shelf

Come with unit: one adjustable shelf (2 compartments)
Material: 304 stainless steel

Door and gasket

Inner door: two, stainless steel
External door: one, with four layers of silicone sealing gaskets, lock-able

Access port

One

Noise level

46 dBA

Communication

Standard: RS-485, USB (stores 15 years of data for compliance purpose)

Working environment

Temperature: 10°C to 32°C (humidity <57% Rh required at 32°C)
Humidity: <80% Rh
Altitude: < 2000 m / 6561 Ft
Stable, well-ventilated platform with no excessive dust
Keep freezer at least 12 inches from any walls or ceiling
Use dedicated power, do not share outlet
Extension power cable should be less than 10 feet is required
Freezer and power outlet should be grounded properly
Avoid direct sunlight, water spill and do NOT use freezer outdoor
Clean condenser fins and remove frost inside chamber at least once a month
Important! Do not plug in your unit. Leave your Ai refrigerator or freezer for 24 hours before turning the unit on for the first time.

Battery backup system

48 hours (for controller display and alarms only)

Unit/shipping weight & dimensions

240 Lbs / 300 Lbs
30 x 26 x 32" / 33 x 29 x 35" (WxDxH)

Safety

Compressor over-temp protection
Ambient over-temp protection
Compressor power surge delay protection
Password protection
Sensor failure protection
Over-temperature and low-temperature protection
Power failure protection
Low battery, door open, condenser clogging, system failure alarms
External door with lock
Ground protection

Product Details

Electrical requirements

110V (+/-10%) 60Hz 1-Phase 680W 6A

Power consumption

5.5 kW/day

Performance

Temperature range: -40°C to -86°C
Time from ambient to -86°C: 4 hours
Uniformity: ±4°C
Time from -86°C to -50°C with door close (ambient 25°C): 2 hours

Controller

Style: microcomputer controlled with analog display
Range -40°C to -86°C
Step: 1°C
Thermo sensor: PT100
Displays: internal temperature, ambient temperature, input voltage, error code
Indicators: Locked, running, power, alarm, door open, over temperature battery low, condenser clean

Compressor

Make: SECOP (formerly known as Danfoss), Germany
Style: direct cooling
Power: 115V 60Hz 1-PHASE, 0.54HP
Number of compressors: one
HC refrigerants: R600A, R1150 and R50

Chamber

Dimensions: 13 x 19.5 x 24.5" (WxDxH)
Material: powder coated steel
Effective capacity: 3.5 Cu Ft
Insulation: VIP (Vacuum Insulated Panel)

Shelf

Come with unit: one adjustable shelf (2 compartments)
Material: 304 stainless steel

Door and gasket

Inner door: two, stainless steel
External door: one, with four layers of silicone sealing gaskets, lock-able

Access port

One

Noise level

46 dBA

Communication

Standard: RS-485, USB (stores 15 years of data for compliance purpose)

Working environment

Temperature: 10°C to 32°C (humidity <57% Rh required at 32°C)
Humidity: <80% Rh
Altitude: < 2000 m / 6561 Ft
Stable, well-ventilated platform with no excessive dust
Keep freezer at least 12 inches from any walls or ceiling
Use dedicated power, do not share outlet
Extension power cable should be less than 10 feet is required
Freezer and power outlet should be grounded properly
Avoid direct sunlight, water spill and do NOT use freezer outdoor
Clean condenser fins and remove frost inside chamber at least once a month
Important! Do not plug in your unit. Leave your Ai refrigerator or freezer for 24 hours before turning the unit on for the first time.

Battery backup system

48 hours (for controller display and alarms only)

Unit/shipping weight & dimensions

240 Lbs / 300 Lbs
30 x 26 x 32" / 33 x 29 x 35" (WxDxH)

Safety

Compressor over-temp protection
Ambient over-temp protection
Compressor power surge delay protection
Password protection
Sensor failure protection
Over-temperature and low-temperature protection
Power failure protection
Low battery, door open, condenser clogging, system failure alarms
External door with lock
Ground protection

Note

Note: Please read description carefully. Do not base your order on the picture presented.
