1 Bulb Xenon Strobe Array with Remote Controller, 10" Width, 120 VAC
The ST-328 is a permanent mount stroboscope array utilizing bright, high-powered xenon style lamps. The ST-328’s xenon light array provides a bright, stable strobe light over a wide measurement range. The arrays are easily mountable on production equipment. Integral or optional remote control is available to program the unit. If selecting the separate, external control enclosure, communication is via a 9.8’ (3 m) connecting cable. Operation is simple with the 6 button keypad and large, LED display. Flash rate is quickly adjustable via the control dial. The unit can work off user programmed flash frequency or from a remote sensor’s signal which will automatically adjust to corresponding process fluctuations.
The ST-328 is designed for speed and frequency measurements in the printing, packaging, textile, automotive, cable, mining, steel, chemical, optical, medical and shipbuilding industries in various applications.
Includes:
- 6.5’ (2 m) AC power cord
- 9.8’ (3 m) control/array connection cable
Features:
- Flash Range of 60 – 20,000 Flashes/min. can be finely adjusted to meet almost any application
- IP65/NEMA 4X Control
- Input sensor trigger function allows process machinery to control flash rate
- Nine standard size lengths from 10” (260 mm) to 71” (1800 mm). Custom options available
- x2 and 1/2 keys for large adjustment rate change or +/- for fine tuning
- Selectable FPM or Hz operation
- Independent Removable bulbs aids in maintenance
- Integral or remote control operations
- Bright red LED aids viewing from a distance or in dimly lit areas
