Buy Shimpo DAG2002-1, 1 Chanel Air Gage Micrometer Display

info@MegaDepot.com

(800) 884-5767
+1 (332) 900-3727 (Intl.)

Options and Related Products

Shimpo, DAG2002-1, 20um 1 Chanel Air Gage Micrometer Display for Use w/ Air Gage Sensor

Features:

4 Digit, 3 color display with 5 light judgment rank makes it easy to quickly view measurements and make go/no-go judgments
Actual values presented on the 8-digit alphanumeric display
In coordination with the max./min. masters and the air probe sensor, control keys are used to automatically calibrate the zero and full scale of the display
10 settings can be programmed to save master values allowing quick retrieval for future tests
Sensitivity adjustment knob allows fine tuning for more precise air control
External signal input allows for automatic master calibration of zero and span with separate input switch
Utilizing the standard serial output communications, data can be downloaded to a PC for processing and further evaluation
Several options are available such as rank judgment and judgment result output, rank output, peak reading, BCD output, and Digimatic output

We aim to show you accurate product information. Here you will find what the manufacturers have provided us with. See our disclaimer.

Technical Details

Input	1 air channel
Measuring range μm (mm)	20 (0.0200)
Resolution in μm (mm)	0.2 (0.0002)
Shift Range	±1000% (full scale)
Display	4 digit 3 color with 5 lamp judgment rank indication
Auto Mastering Range	Zero position: ±50% (full scale)
Auto Mastering Range	Sensitivity: ±20% (full scale)
Power Requirement	85 to 264 VAC, 50/60 Hz 100-VAC
Power Supply Capacity	30 VA
Air Supply Pressure	28.4 PSI (196 kPa)
Source Pressure	43.5 PSI (300 kPa) to 101.5 PSI (700 kPa)
Air Supply Volume	106 cfh (50 l/min)
Operating Temperature	32 to 113°F (0 to 45°C)
Dimensions	4.7" wide x 7" deep x 6" height (120 x 180 x 150 mm)
Weight	4.85 lb (2.2 kg)
Warranty	1-Year

Notes

* Free Ground Shipping within the continental U.S. only (excludes Alaska, Hawaii, PO Boxes and APO/FPO addresses).

Input	1 air channel
Measuring range μm (mm)	20 (0.0200)
Resolution in μm (mm)	0.2 (0.0002)
Shift Range	±1000% (full scale)
Display	4 digit 3 color with 5 lamp judgment rank indication
Auto Mastering Range	Zero position: ±50% (full scale)
Auto Mastering Range	Sensitivity: ±20% (full scale)
Power Requirement	85 to 264 VAC, 50/60 Hz 100-VAC
Power Supply Capacity	30 VA
Air Supply Pressure	28.4 PSI (196 kPa)
Source Pressure	43.5 PSI (300 kPa) to 101.5 PSI (700 kPa)
Air Supply Volume	106 cfh (50 l/min)
Operating Temperature	32 to 113°F (0 to 45°C)
Dimensions	4.7" wide x 7" deep x 6" height (120 x 180 x 150 mm)
Weight	4.85 lb (2.2 kg)
Warranty	1-Year

Note: Please read description carefully. Do not base your order on the picture presented.
