The actual item's colors maybe different from what is shown on the product picture.

Options and Related Products

Range (PSI):: Range (PSI): 0/15
Case Filling:: Case Filling: Dry

Pic Gauges, 304D-158B, 300 Series All Stainless 1.5" Standard Pressure Gauge, 1/8" NPT Male Connection, Back Connection, Front Flange, Panel Mount, Dry, 0/15 psi

Features:

Heavy duty, all stainless steel gauge with welded case-to-stem connection
Stainless steel case and bezel
316 stainless steel internals

See more product information See less

We aim to show you accurate product information. Here you will find what the manufacturers have provided us with. See our disclaimer.

Technical Details

Reviews

Dimensions

A: 1.83" / 46 mm
B: 1.01" / 26 mm
C: 0.89" / 23 mm
D: 1.90" / 48 mm
E: 1/8" NPT
F: 2.46" / 63 mm
G: 1.61" / 43 mm

Dial

1.5" (40 mm)

Case

Stainless steel
Welded case-to-stem connection

Wetted Parts

316 stainless steel

Bezel

Stainless steel, fixed

Lens

Polycarbonate

Connection

Center back mount with front flange

Scale

Single scale psi

Accuracy

2-1-2% of span 2-1/2" ASME B40.1

Ambient Temperature

-30° F to 180° F

Product Details

Dimensions

A: 1.83" / 46 mm
B: 1.01" / 26 mm
C: 0.89" / 23 mm
D: 1.90" / 48 mm
E: 1/8" NPT
F: 2.46" / 63 mm
G: 1.61" / 43 mm

Dial

1.5" (40 mm)

Case

Stainless steel
Welded case-to-stem connection

Wetted Parts

316 stainless steel

Bezel

Stainless steel, fixed

Lens

Polycarbonate

Connection

Center back mount with front flange

Scale

Single scale psi

Accuracy

2-1-2% of span 2-1/2" ASME B40.1

Ambient Temperature

-30° F to 180° F
