| Video/Audio Input |
| IP Video Input | 128 CH |
| Incoming/Outgoing Bandwidth | 768 Mbps / 768 Mbps |
| Incoming/Outgoing Bandwidth (RAID mode) | 768 Mbps / 768 Mbps |
| Protocol | LTS, ACTi, ARECONT, AXIS, BOSCH, BRICKCOM, CANON, HUNT, ONVIF (Version 2.5), PANASONIC, PELCO, PSIA, RTSP, SAMSUNG, SONY, VIVOTEK, ZAVIO, HIKVISION |
| Video/Audio Output |
| HDMI Output | Two independent HDMI outputs of 4K resolution. Resolution: 4K (4096x2160), 4K (3840x2160)/30Hz, 2K (2560x1440)/60Hz, 1080P (1920x1080)/60Hz, UXGA (1600x1200)/60Hz, SXGA (1280x1024)/ 60Hz, 720P (1280x720)/60Hz, XGA (1024x768)/60Hz |
| VGA Output | 1CH Resolution: 1080P (1920x1080) /60Hz, UXGA (1600x1200) /60Hz, SXGA (1280x1024) /60Hz, 720P (1280x720) /60Hz, XGA (1024x768) /60Hz |
| Audio Output | 1CH, RCA (Linear, 1kΩ) |
| Video & Audio Decoding |
| Decoding Format | H.265, H.265+, H.264, H.264 Zip+, MPEG4, MJPEG |
| Video Resolution | 12MP/8MP/7MP/6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
| Synchronous Playback | Up to 16 channels |
| Capability | 68CH at 1080P |
| Hard Disk |
| SATA | 16 SATA interfaces supporting hot-plug |
| Capacity | Up to 8TB capacity for each HDD |
| RAID |
| RAID Type | RAID 0, 1, 5, 6, and 10 |
| Network Management |
| Protocol | IPv6, HTTPS, UPnP, SNMP, NTP, SADP, SMTP, NFS, iSCSI, PPPoE, DDNS |
| Network Interface | 4, RJ45 10M/100M/1000M self-adaptive Ethernet interface |
| External Interface |
| Two-way Audio Input | 1-ch, RCA (2.0 Vp-p, 1 KΩ) |
| Serial Port | 1 RS-485,Keyboard |
| USB Interface | Front Panel: 2 x USB 2.0; Rear Panel: 2 x USB 3.0 |
| Alarm Input/Output | 16/8 |
| Decoding Board | 1 |
| General |
| Power Supply | 100 ~ 240 VAC, 550W |
| Consumption | ≤ 140 W(without hard disk or DVD-R/W) |
| Working Temperature | 32 °F to 122 °F (0°C to + 50°C) |
| Working Humidity | 10 % ~ 90 % |
| Casing | 19-inch rack-mounted 3U chassis |
| Dimensions (WxDxH) | 17.4" x19.4"x5.7"(442x 494 x146 mm) |
| Weight | ≤ 35.3 lb (16 Kg, without hard disk or DVD-R/W) |
