| Camera |
| Camera Series | Platinum Series |
| Camera Resolution | 6.0MP |
| Camera Technology | IP / Network |
| Camera Housing | Dome |
| Image Sensor | 1/1.8"Sensor |
| Min. Illumination | 0.05 lux at (F1.2, AGC ON),0.3 lux at (F2.8, AGC ON )
0 lux with IR |
| Shutter Speed | 1/25 s to 1/100,000 s |
| Slow Shutter | Support |
| Lens | 1.27mm atF2.0, angle of view: 360° |
| Lens mount | M12 |
| Day & Night | ICR |
| Digital Noise Reduction | 3D DNR |
| Wide dynamic range | Digital WDR |
| Compression Standard | |
| Video Compression | H.264/MPEG4 |
| H.264 Type | Baseline Profile/Main Profile/High Profile |
| Video Bit Rate | 32 Kbps-16 Mbps |
| Audio Compression | G.711/G.726/MP2L2 |
| Audio Bit Rate | 64Kbps(G.711) / 16Kbps(G.726) / 64Kbps (MP2L2) |
| Image | |
| Max Resolution | 3072x2048 |
| Frame Rate | High-frame Mode: support- 60Hz: 1 x fisheye (3072 x 2048, 25fps) or (2048 x 2048, 30fps) or 4 xPTZ at (1024 x768, 30fps)
- 50Hz: 1 xfisheye (3072 x2048, 25fps) or (2048x 2048, 25fps) or 4 xPTZ at (1024 x768, 30fps)
Multi-channel Mode: support- 60Hz: 1 x fisheye (1280 x 1280, 15fps) and 1 x panoramic (2048 x1536, 15fps) and 3x PTZ (1024 x768, 15fps)
- 50Hz: 1 x fisheye (1280 x1280, 12.5fps) and 1 x panoramic (2048 x 1536, 12.5fps) and 3 x PTZ(1024 x 768, 12.5fps)
|
| Image Setting | Saturation, Brightness, Contrast, Hue, Sharpness, AGC, White Balance |
| High Light Compensation | Support |
| Day/night Switch | Auto / Schedule / Alarm trigger |
| Network |
| Network Storage | NAS, SAMB / CIFS |
| Alarm trigger | - Motion detection, dynamic analysis, tamper alarm, network disconnect,
- IP address conflict,storage full, storage error
|
| Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE,
NTP, UPnP, SMTP,SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour |
| Security | User Authentication, Watermark, IP address filtering, Anonymous access |
| Standard | ONVIF, PSIA, CGI |
| Interface |
| Communication Interface | 1 RJ45 10M/100M Ethernet port, 1 RS-485 interface |
| On-board storage | Built-in Micro SD/SDXC slot, up to 64 GB |
| General |
| Working Temperature/Humidity | - -22 °F - 140 °F(-30 °C - 60 °C )
- Humidity 95% or less (non-condensing)
|
| Power Supply | 12V DC/ PoE |
| Power Consumption | Max.11W |
| IR range | Max. 10m(33ft) |
| Protection | IEC 60068-2-75 test, Eh, 50J; EN 50102, EN50155 |
| Dimension | 6.6"x 1.7"(167.4 x 43.8mm) |
| Weight | 1.7lb(800g) |
